Daewoo COL1587 - Description of Parts - Control Panel; Control Panel Overview and Functions

8
16L Dehumidifier
Model No. COL1587
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts – Control Panel
Item
Item Description
Symbol
Description/comments
10
On/Off Button
Press to switch the unit on
and off.
11
Mode Button
Press to select Sunny, Rainy
or continuous Drying mode.
12
Fan Speed/ Child Lock
Button
Press to select high or low
fan speed, press and hold
for child lock.
13
Humidity Button
Press to adjust humidity set
point from 20-95%.
14
Sleep Button
Press to switch Sleep mode
on and off.
15
Timer Button
Press to set the time for the
unit to start or stop.
16
Child Lock Indicator
Lights when the child lock is
activated.
17
Fan Speed Indicators
18
Water Tank Full Indicator
Lights when the Water Tank
is full.
19
Mode Indicators
20
Digital Display
10
11
12
14
15
16
13
17
18
20
19
Low
High
Sunny
Drying
Raining
