CP-520/520A/520F Service Manual
DTV- R&D Europe
DTV- R&D Europe
z_loc z_parts_code parts_name parts_descr remark
z_loc z_parts_code parts_name parts_descr remark
R540 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R541 RN-AZ3902F R METAL FILM 1/6 39K OHM F
R542 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R543 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R544 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R545 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R546 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R547 RD-AZ563J- R CARBON FILM 1/6 56K OHM J
R551 RD-AZ823J- R CARBON FILM 1/6 82K OHM J
R552 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R553 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R554 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R555 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R556 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R557 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R558 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R559 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R560 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R561 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R562 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R563 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R564 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R565 RD-AZ154J- R CARBON FILM 1/6 150K OHM J
R566 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R567 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R568 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R569 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R571 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R572 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R573 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R574 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R575 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R576 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R577 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R578 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R579 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R580 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
R581 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R582 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R583 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R584 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R585 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R586 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R587 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R588 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R589 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R590 RD-AZ334J- R CARBON FILM 1/6 330K OHM J
R598 RD-AZ182J- R CARBON FILM 1/6 1.8K OHM J
R599 RD-AZ224J- R CARBON FILM 1/6 220K OHM J
R601 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R602 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
R608 RD-2Z151J- R CARBON FILM 1/2 150 OHM J
R609 RD-2Z151J- R CARBON FILM 1/2 150 OHM J
R610 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R611 RD-AZ474J- R CARBON FILM 1/6 470K OHM J
R612 RD-AZ474J- R CARBON FILM 1/6 470K OHM J
R650 RD-AZ303J- R CARBON FILM 1/6 30K OHM J
R660 RD-AZ303J- R CARBON FILM 1/6 30K OHM J
R661 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R662 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R700 RD-2Z332J- R CARBON FILM 1/2 3.3K OHM J
R713 RD-AZ681J- R CARBON FILM 1/6 680 OHM J
R720 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R721 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R722 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R723 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R724 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R805 RD-2Z100J- R CARBON FILM 1/2 10 OHM J
R806 RD-2Z472J- R CARBON FILM 1/2 4.7K OHM J
R807 RD-2Z272J- R CARBON FILM 1/2 2.7K OHM J
R808 RD-2Z821J- R CARBON FILM 1/2 820 OHM J
R810 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R811 RC-2Z565KP R CARBON COMP 1/2 5.6M OHM K
R812 RD-4Z473J- R CARBON FILM 1/4 47K OHM J
R813 RD-4Z473J- R CARBON FILM 1/4 47K OHM J
R814 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R815 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R816 RD-4Z399J- R CARBON FILM 1/4 3.9 OHM J
R817 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R820 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R821 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R823 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R829 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R830 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R840 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R841 RD-2Z479J- R CARBON FILM 1/2 4.7 OHM J
R842 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R850 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R870 RD-2Z222J- R CARBON FILM 1/2 2.2K OHM J
R901 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R910 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R911 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R912 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R913 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R914 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R915 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R921 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R922 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R923 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R996 RD-2Z105J- R CARBON FILM 1/2 1M OHM J
R997 RD-2Z102J- R CARBON FILM 1/2 1K OHM J
RA02 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA03 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA04 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA05 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RA06 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA07 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
RA08 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA09 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA10 RD-AZ470J- R CARBON FILM 1/6 47 OHM J
RA11 RD-AZ680J- R CARBON FILM 1/6 68 OHM J
RA12 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RA13 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
RA14 RD-AZ220J- R CARBON FILM 1/6 22 OHM J
RA15 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA16 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA17 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RA18 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
RA19 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA23 RD-AZ220J- R CARBON FILM 1/6 22 OHM J
RA24 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
RA25 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RA29 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA32 RD-AZ470J- R CARBON FILM 1/6 47 OHM J
RA35 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
ZZ140 PTPKCPY28A8F PACKING AS DTY-28A8FZF
M681 2TP06575CL TAPE OPP T0.065XW75X500M CLEAR
M801 GPBBW5B1122 BOX DTE-28B1 (NEW)
M811 4858199C01UP PAD UP EPS 28A8
M811A 4858199C01DN PAD DOWN EPS 28A8
M822 4858215601 BAG P.E. “PE FOAM T0.5X1600X1270 25””-28”” “
