41
Flywheel 1
42
Flameout line 1
43 Half round key 3*13 1
44 Big cross head M5*8 4
45
Oil plate of left crankcase 1
46 Oil seal 15*26*5 2
47 Crankcase 1
48 Crankcase rubber shock 1
49 Crankcase gasket 1
50 Pin sleeve 5*7*12 2
51 Open bearing 6202 2
52 Crankshaft cover 2
53 Crankshaft 1
54 Needling 12*15*14.7 1
55
Piston pin spring 12 2
56
Piston pin 12*33 1
57
Piston 1
58 Piston ring 2
59 Cylinder gasket 1
60
Hexagon socket head combination screw
M5*35
2
61
Muffler 1
62 Muffler gasket 2
63 Muffler air guide pad 1
64
Cylinder 1
65
Hexagon socket head combination screw
M5*30
4
66
Spark plug 1
67
Wind shield 1
68 Pressure reducing valve 1
69 Cylinder shock spring 2
70 Cylinder shock spring seat 1
71 Inlet pipe seat 1
72 Hexagon socket head screw M5*10 3
73 Negative pressure nozzle 4 1
74 Double hole intake pipe 1
75
Negative pressure pipe 1
76
Hexagon socket head combination screw
M5*14
7
77 Inlet pipe flange 1
78 Carburetor 1
79
Carburetor gasket 1
80 Air filter seat 1
