1. Seat
5. Battery charging socket
9. Catch basket
13. Gear switching
17. Pull cable starter
21. Exhaust pipe
2. Steering wheel
6. Waterconnection
10. Rear wheels
14. Throttle
18. Fuel tank cover
22. Spark plug
3. Brake Pedal
7. Cutting height setting
11. Ejector chute
15. Seat position adjutament
19. Air lter
23. Head light (Alternative)
4. Front tyres
8. Mover on/off
12. Ignition lock
16. Locking brake
20. Oil tank cover
24. Head light switch (Alternative)
3. SCOPE OF DELIVERY
· Open the packaging and remove the device carefully.
· Remove the packaging material as well as the packaging and trans-
port bracing (if available)
· Check that the delivery is complete.
· Check the device and its spare parts for possible damage caused by
transportation. In the event of complaints, you must
contact the distributor without delay. Claims at a later stage will not be
accepted.
· If possible, store the packaging until the warranty period has expired
· Before handling the device, make yourself familiar with it by reading
the operating instructions.
· For accessories, consumables and spare parts, only use original
parts. Spare parts are available from your stockist.
· Include our item number, the device model and year of manufacture in
your order.
4. PROPER USE
The machine meets the currently valid EU machine directive.
Caution – risk of accident:
The ride-on mower is only intended for mowing lawns; its use
