- 97 -
(2) DE12TI-310
(a) Main data and specifications
Part No. : 65.11101 - 7297
Model : PE6P type
Governor : RFD+D type
Timer : SPG type, range of operation: 3°/700-1100 rpm
Plunger : 65.11125-0010
Delivery valve : 65.11108-6009
Fuel feed pump : 65.12101-7013
Pre-stroke : 4.2L0.05mm
Rotating direction : C.W. at driving gear side
Injection order : 1-5-3-6-2-4
Injection timing : BTDC 12°
(b) Calibration data
Adjusting
Rack position Pump speed Injection volume
Variation Basic Fixing Ref.
point (mm) (rpm) (mm
3
/1,000st) rate (%) point point
A 9.2 1,050 154L2 L20
B 5.1 250 16L1.5 L15
C - 100 100 -
D 9.7 500 170L3-
E 7.1 500 115L3-
Contents Specifications Engine application
Nozzle holder assembly 105780-8140 65.10101-7072
Nozzle 105780-0000 65.10102-6034
Nozzle holder 105780-2080
Opening pressure 175 kg/cm
2
1st : 160 kg/cm
2
, 2nd : 220 kg/cm
2
Injection pipe N8 B N3 - 600mm N6 B N2 - 650mm
Fuel delivery pressure 1.6 kg/cm
2
Fuel temperature 35~45 C
Adjusting
conditions
