- 99 -
(3) DE12TI(A)
(a) Main data and specifications
Part No. : 65.1101-7287(106671-9130)
Model : PE6P type
Governor : RFD+D type
Timer : SD type, range of operation: 3°/700-1100 rpm
Plunger : 65.11125-0010
Delivery valve : 65.11108-6009
Fuel feed pump : 65.12101-7013
Pre-stroke : 4.2L0.05mm
Rotating direction : C.W. at driving gear side
Injection order : 1-5-3-6-2-4
Injection timing : BTDC 12°
(b) Calibration data
Adjusting
Rack position Pump speed Injection volume
Variation Basic Fixing Ref.
point (mm) (rpm) (mm
3
/1,000st) rate (%) point point
A R1 1,050 171L2 L20
B R2 250 14.5L1.5 L15
C - 100 115 -
DR1L0.5 500 (186.5)L3-
ER1L2.5 500 (122)L3-
Contents Specifications Engine application
Nozzle holder assembly 105101-7971 65.10101-7294
Nozzle 105029-1320 65.10102-6043
Nozzle holder 105030-4711
Opening pressure 175 kg/cm
2
1st : 160, 2nd : 220 kg/cm
2
Injection pipe N8 B N3 - 600mm N6 B N2.2 - 650mm
Fuel delivery pressure 1.6 kg/cm
2
Fuel temperature 35~45 C
Adjusting
conditions
