If user selects the
model then following screen will be dis-
played.in here, user can select a test tar-
get unit.
And, if user selects the
then the right screen will be displayed.
In here, user must select Daewoo vehi-
cle model one of them.
If user selects a model and press the
ENTER key then the right messages will
be displayed.
If Daewoo vehicle model was not matched with communication protocol or any error occurred,
then above FAULT message is displayed.
If NORMAL message displayed, then program goes on next screen.
And the right screen will be displayed as
a result of unit check.
In here, press the key to go on
next screen.
Now, user can test concerned with elec-
troic control engine.
ENTER
Engine Control Unit
DAEWOO BUS
- 143 -
COMMUNICATION CHECK
ENGINE MODEL : DE12TIS
DHI ECU NO : 65.12201-7001
DHI ROM NO : 65.99901-0001
ZEXEL ECU NO : 2860
ZEXEL ROM NO : 1320
PART NO : EF.123-157
COMMUNICATION ERROR
Communication falt !
Check on connection and do it
again
Line and unit
checking now
Please wait a
moment
[ NORMAL ] [ FAULT ]
SELECT DAEWOO VEHICLE
02. DAEWOO TRUCK
01. DAEWOO BUS
SELECT CONTROL UNIT
02. Antilock Brake System
01. Engine Control Unit
SELECT BUS MODEL
02. DIESEL 4500 SOHC(BOSCH)
03. CNG 4500C(WOODWARD)
01. DIESEL 4500 SOHC(ZEXEL)
SELECT DIAGNOSIS ITEM
02. SELP-DIAG (PAST)
03. SENSOR DATA
04. ACTUATOR TEST
05. FLIGHT RECORD
01. SELF-DIAG (CURRENT)
