- 151 -
CODE Fault Point Regular Specification Repair Hint
C16 ENGINE SPEED Error in engine RPM 1.Check the signal between
SENSOR ERROR sensor pin No.10 pin and pin No.23 of ECU
2.Check the resistance of pick-up sensor :
2.5`0.5K
3.Check if cable is short or open
4.Check the contracts of connector
C14 PRESTROKE Error in prestroke CHECKING CONDITION-Key on
OFFSET LEARNING offset learning 1.Check the resistance of prestroke actuator
ERROR sensor as follow
pin No.6 pin and pin No.7 of ECU
pin No.6 pin and pin No. 19 of ECU
pin No.7 pin and pin No. 29 of ECU
2.Check the ECU
3.Check if cable is short or open
4.Check the contacts of connector
C13 PRESTROKE Error in prestroke CHECKING CONDITION-Key on
SENSOR ERROR sensor REGULAR VALUE-f=18`2kHz
1.Check the resistance of prestroke
actuator sensor as follow
pin No.6 pin and pin No.7 of ECU
pin No.6 pin and pin No.19 of ECU
pin No.7 pin and pin No.29 of ECU
2.Check the prestroke sensor
3.Check if cable is short or open
4.Check the contacts of connector
C12 PRESTROKE Error in prestroke CHECKING CONDITION-Key on
CONTROL SERVO actuator servo control 1.Check the voltage of prestroke actuator
ERROR sensor as follow
pin No.6 pin and pin No.7 of ECU
pin No.6 pin and pin No.19 of ECU
pin No.7 pin and pin No.29 of ECU
2.Check the prestroke actuator status
3.Check if cable is short or open
4.Check the contacts of connector
