5.6.7 function
User can print the recorded data to press the : F6 function key. Before printing Scan
Pole must be connected with printer via PC connection cable.
Printer is option.
5.6.8 D12TIS diagnosis & repair hint
PRINT
PRINT
- 150 -
CODE Fault Point Regular Specification Repair Hint
C15 PRESTROKE Error in prestroke CHECKING CONDITION-Key ON
ACTUATORPOWER actuator power REGULAR VALUE-24V
ERROR voltage is below 0.8V 1.Check the voltage between pin no.27 pin
and pin no.47 ECU
2.Check if cable is short or open
3.Check the contacts of connector
C21 WATER Error in water CHECKING CODITION-Key ON
TEMP.SENSOR temperature sensor 1.Check the resistance between pin
ERROR circuit or water NO.5 pinand NO.24ofECU as follow
temperature sensor TEMP. RESISTANCE
20 2500
40 1170
60 594
80 310
2.Check the water temperature sensor
3.Check if cable is short or open
4.Check the contacts of connector
C22 FUEL RACK Error is fuel rack CHECKING CONDITION-Key on, Running
SENSOR ERROR sensor or circuit REGULAR VALUE - Running
= below 0.2V - IDLE : below 3.49V
1.Check the voltage between pin NO.8 pin
and pin No.9 of ECU
2.Check the fuel rack sensor
3.Check if cable is short or open
4.Check the contacts of connector
C23 INTAKE AIR Fail in intake air CHECKING CONDITION-Key off ->Key on
HEATER RELAY heater relay or circuit REGULAR VALUE
ERROR -Key OFF : 24V
Key ON : 0V
1.Check the voltage between pin no. 12
and pin No.47 of ECU
2.Check the intake air heater relay
3.Check if the cable is short or open
4.Check the contacts of connector
To Next Page
