6.1.3. Standard bolt tightening torque table
Refer to the following table for bolts other than described above.
Degree of strength
3.6 4.6 4.8 5.6 5.8 6.6 6.8 6.9 8.8 10.9 12.9
(4A) (4D) (4S) (5D) (5S) (6D) (6S) (6G) (8G) (10K) (12K)
Limit value for elasticity (kg/mm
2
)
20 24 32 30 40 36 48 54 64 90 108
Tightening torque (kg•m)
M5 0.15 0.16 0.25 0.22 0.31 0.28 0.43 0.48 0.50 0.75 0.90
M6 0.28 0.30 0.45 0.40 0.55 0.47 0.77 0.85 0.90 1.25 1.50
M7 0.43 0.46 0.70 0.63 0.83 0.78 1.20 1.30 1.40 1.95 2.35
M8 0.70 0.75 1.10 1.00 1.40 1.25 1.90 2.10 2.20 3.10 3.80
M8
B
1 0.73 0.80 1.20 1.10 1.50 1.34 2.10 2.30 2.40 3.35 4.10
M10 1.35 1.40 2.20 1.90 2.70 2.35 3.70 4.20 4.40 6.20 7.40
M10
B
1 1.50 1.60 2.50 2.10 3.10 2.80 4.30 4.90 5.00 7.00 8.40
M12 2.40 2.50 3.70 3.30 4.70 4.20 6.30 7.20 7.50 10.50 12.50
M12
B
1.5 2.55 2.70 4.00 3.50 5.00 4.60 6.80 7.70 8.00 11.20 13.40
M14 3.70 3.90 6.00 5.20 7.50 7.00 10.00 11.50 12.00 17.00 20.00
M14
B
1.5 4.10 4.30 6.60 5.70 8.30 7.50 11.10 12.50 13.00 18.50 22.00
M16 5.60 6.00 9.00 8.00 11.50 10.50 15.50 17.90 18.50 26.00 31.00
M6
B
1.5 6.20 6.50 9.70 8.60 12.50 11.30 17.00 19.50 20.00 28.00 33.50
M18 7.80 8.30 12.50 11.00 16.00 14.50 21.00 24.20 25.00 36.00 43.00
M18
B
1.5 9.10 9.50 14.50 12.50 18.50 16.70 24.50 27.50 28.50 41.00 49.00
M20 11.50 12.00 18.00 16.00 22.00 19.00 31.50 35.00 36.00 51.00 60.00
M20
B
1.5 12.80 13.50 20.50 18.00 25.00 22.50 35.00 39.50 41.00 58.00 68.00
M22 15.50 16.00 24.50 21.00 30.00 26.00 42.00 46.00 49.00 67.00 75.00
M22
B
1.5 17.00 18.50 28.00 24.00 34.00 29.00 47.00 52.00 56.00 75.00 85.00
M24 20.50 21.50 33.00 27.00 40.00 34.00 55.00 58.00 63.00 82.00 92.00
M24
B
1.5 23.00 25.00 37.00 31.00 45.00 38.00 61.00 67.00 74.00 93.00 103.00
- 155 -
Others:
1. The above torque ratings have been determined to 70% or so of the limit value for bolt elasticity.
2. Tension is calculated by multiplying tensile strength by cross section of thread.
3. Special screws should be tightened to 85% or so of the standard value.
For example, a screw coated with MOS2 should be tightened to 60% or so of the standard
value.
Diameter
B
pitch
(mm)
