Daewoo DE12 - 4. Maintenance of Major Components

3.3.36. Intake manifold
1) Fit a gasket on the intake manifold
before assembling the intake manifold.
2) Mount the air heater gasket on the
intake manifold, then assemble the air
heater with the intake manifold.
3) Connect the air hose to the boost com-
pensator mounted on the fuel injection
pump.
- 76 -
EQM3100I
3.3.37. Injection pipe
1) Semi-assemble a nut at both ends of
the fuel high pressure pipe and tighten
them up one by one to specified torque.
2) Tighten hollow screws to assemble the
fuel return pipe.
3) Assemble the fuel return hose with the
fuel injection pump.
EQM3101I
3.3.38. Fuel filter
1) Assemble the fuel filter at bracket.
2) Assemble the fuel hose.
EQM3102I
3.3.39. Cylinder head cover
1) Assemble the cover packing with the
cover, install the cover on the head,
then tighten the fixing bolts in sequence
to specified torque (1.5kg
•
m).
2) Assemble the breather hose with PCV
valve.
EQM3103I
