3.3.40. Air-conditioning compressor
1) Install the A/C compressor mounting
bracket on the timing gear case.
2) Install the alternator mounting bracket
on the timing gear case, then install A/C
compressor fixing bolts.
3) Tighten the fixing bolts.
- 77 -
EQM3104I
3.3.41. Alternator
1) Install the alternator mounting bracket
with a fixing bolt onto the cylinder head.
2) Install the alternator in position.
EQM3105S
3.3.42. Cooling fan
1) Install the cooling fan and flange onto
the fan coupling.
2) Install the flange onto the crank pulley.
EQM3106I
3.3.43. V-belt
1) Install the V-belt on the crank pulley,
idle pulley and alternator pulley.
2) Adjust the V-belt tension using the A/C
compressor tension adjusting bolt.
3) Install another V-belt on the idle pulley
and alternator pulley.
4) Adjust the V-belt tension using the
alternator tension adjusting bolt.
EQM3107I
