7. Waveforms of Major Check Method
Audio Out Signal Waveform
DAC Output Signal Waveform
Optical Output Audio Data Signal waveform
L/R Clock Data Waveform During Normal Play
Serial Data Output Waveform During Normal Play
16
TEST POINT : DVD TEST DISC MDVD-W111 TRACK2 COLOR BAR
