6. DISASSSEMBLY AND ASSEMBLY
6-1. METHODS OF EXCHANGING PARTS IN FREEZER
1) F-LOUVER
2) F-LAMP AND SOCKET AS (only DIR-300)
20
A. Untie f-louver’s screw with the "+"
driver. (2 Spots)
B. Before removing the f-louver,
pulling the F (lamp) window
downward. (only DIR-300)
C. Remove the f-louver by pulling
forward with inserting fingers into
the f-return hole of f-louver.
C. To exchange the interior lamp,
unscrew the lamp counterclockwise.
