NO CODE PART NAME QT’Y MATERIAL SPEC. REMARK
1 3010316610 BASE COMPRESSOR SAS 1 DIR-300
2 3010100201 ABSORBER COMPRESSOR 4 NR H=40mm
3 3958123C50 COMPRESSOR 1 SL23YE-5-C 220~230V/50Hz
4 4019H09030 SPECIAL WASHER 4 SWRH
5 3818117200 SWITCH P-RELAY AS 1 230V/50Hz
6 3816100100 BAND RELAY 1 SK-5 T0.7 ZN-3-A
7 3010515800 BOX POWER AS 1 DIR-220
8 7112401211 SCREW TAPPING 2 MFZN T1 TRS 4X12
9 3014419600 PIPE VAPORI AS 1 DIR-220
10 3014425100 PIPE COOLING 1 DTW 4.76XT0.7
11 3014425000 PIPE CONNECTOR 1 DCUT1-0 6.0XT0.6
12 3014419500 PIPE HOT 1 DTW 4.76XT0.7
13 3014419400 PIPE CONDENSER 1 DTW 4.76XT0.7
14 3016802500 DRYER AS 1 XH-5 10gr
15 3014419300 PIPE SUCTION AS 1 DIR-300
16 3014419800 PIPE SUCTION CONNECTOR 1 DUCT1-0 6.0XT0.6
17 3011300100 CORD POWER 1 BP-3PIN AC 250V/6A
18 7002401065 SCREW MACHINE 1 BSNI TRS 4X10
19 7112401211 SCREW TAPPING 1 MFZN T1 TRS 4X12
38
