-28-
8. Service part list
ZZ100 48B5849C10 TRANSMITTER REMOCON R-49C10 (AAA)
ZZ110 PTACPWG121 ACCESSORY AS DLP-20J1AHS
00010 4850Q00910 BATTERY R03/NN
M821 4858213803 BAG INSTRUCTION L.D.P.E TO.05X250X400(+20)
M861 48586110R1 MANUAL INSTRUCTION RUSSIAN
ZZ120 PTBCSHG145 COVER BACK AS DLP-20J1BHS
M211 4852176301 COVER BACK HIPS BK
M321 4853296300 BRKT VESA SECC T0.8
M321A 7178300851 SCREW TAPPTITE TT2 WAS 3X8 MFZN 3CR
M751 4857541301 COVER JACK HIPS BK
ZZ130 PTPKCPG145 PACKING AS DLP-20J1BHS
M801 4858071100 BOX CARTON DW-3
M811 485819CM00 PAD EPS
M821 4858215701 BAG P.E PE FOAM t0.5x1050x950
ZZ140 PTCACAG177 CABINET AS DLP-20J1LHS
M1F1 4851F02200 STAND AS DLP-20J1/J3
M1F1A 7172401652 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK 3CR
M201A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M201B 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M201C 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M201D 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M211A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M361 4853635301 TERMINAL COVER HIPS BK
M361A 7178301052 SCREW TAPPTITE TT2 WAS 3X10 MFZN BK 3CR
M381 4853829303 FRAME MAIN PCB SECC T0.8 LPL
M381A 7008301451 SCREW MACHINE WAS 3X14 MFZN 3CR
M381B 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M381C 4956800200 CLAMP WIRE WS-A-2-19
M541 4855421300 SPEC PLATE 150ART P/E FILM (C/TV)
P902A 4859006560 CABLE FFC 0.50P-50N-110L-T5
PWC1 48599NS001 CORD POWER AS CENT-AM KKP-419C+YH396-43V=2.0M
V901 485LD03205 LCD PANEL LC201V02-SDA3
V902 485AS00780 POWER LIPS IPB-6015N01DP
ZZ200 PTFMSJG145 MASK FRONT AS DLP-20J1BHS
M201 4852093411 MASK FRONT HIPS GY
M201E 4857743900 CUSION PANEL PVC 300 X 10 T=1.0
M551 4855556500 DECO SENSOR GPPS MILKY
M551A 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
M561 48556192SD MARK BRAND SILVER DIA-CUTTING
ZZ210 PTSPPWG121 SPEAKER AS DLP-20J1AHS
SP01 4858318310 SPEAKER SP-5090F01C
SP01A 4850703S51 CONNECTOR YH025-03+35098+ULW=300
SP02 4858318310 SPEAKER SP-5090F01C
SP02A 4850703S51 CONNECTOR YH025-03+35098+ULW=300
ZZ290 PTMPMSG177 PCB MAIN MANUAL AS DLP-20J1LHS
10 2193110001 SOLDER WIRE SN-3.0AG(NP303T) 3.0
20 2193110002 SOLDER WIRE SN-3.0AG-0.5CU(DHB-RMA3) 1.6
30 2291050619 FLUX SOLDER SV-PBF-05(0.824)
40 2291050314 FLUX SOLVENT IM-1000
A001A 2TW08010YE TAPE PAPER T0.08XW10X50M YELLOW
I502 124LC32A-P IC EEPROM 24LC32A-I/P 32K 8 PIN DIP STICK
I601 PTB2SW7724 HEAT SINK ASS`Y 1LA42032E- + 7174300851
00001 1LA42032E- IC AUDIO AMP LA42032-E
0000A 4857027724 HEAT SINK AL EX
0000B 7174300851 SCREW TAPPTITE TT2 RND 3X8 MFZN 3CR
IC12 1TS0P34838 IC PREAMP TSOP34838SJ
LED1 DSPR39MVW- LED SPR-39MVW (DUAL)
M231 4852333001 PANEL CTRL HIPS BK
M481 4854872011 BUTTON POWER HIPS GY
M491 4854964011 BUTTON CH HIPS GY
M491A 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
P103 4859295520 CONN WAFER 4602-02MV2-60-1 PLUG 2P ST
P103A 4859295620 CONN WAFER 4605-2FV2-1 JUMPER 2P 2.54
P501 4859236220 CONN WAFER YAW025-05
P501A 4859236220 CONN WAFER YAW025-05
P502A 4850705N39 CONNECTOR YH025-05+YH025-05+ULW=100
P504 4859236120 CONN WAFER YAW025-04
P504A 4850704S79 CONNECTOR YH025-04+YBH250-04+ULW=700
LOC PART CODE PART NAME DESCRIPTION REMARK
P601 4859236020 CONN WAFER YAW025-03
P602 4859236020 CONN WAFER YAW025-03
P803 4859236720 CONN WAFER YAW025-10
P803A 4850710S32 CONNECTOR YH025-10+YH025-10+ULW=500
PA041 4859102130 JACK EARPHONE YSC-1537
PA06 4859105340 JACK S-VHS DSW-10 (STRAIGHT)
PA07 4859112850 JACK PIN DPSS-0173 3PIN STR
PA08 4859112950 JACK SCART DSSM-0378 STR
PA09 4859236320 CONN WAFER YAW025-06
PA09A 4850706S46 CONNECTOR YH025-06+YH025-06+ULW=250
PA09C 4859236320 CONN WAFER YAW025-06
PA501 4850705S26 CONNECTOR YH025-05+YH025-05+ULW=350
SW8 5S40101009 SW PUSH PS-22E06
TU2 4850A23840 ANT SHIELD BOX PAXBF01DA (PAL)
U100 4859728430 TUNER VARACTOR UV1316/A I H-4
X201 5XJ24R576E CRYSTAL QUARTZ HC-49/S 24.576MHZ 30PPM
X501 5XJ24R576E CRYSTAL QUARTZ HC-49/S 24.576MHZ 30PPM
Z101 5PK3953M-- FILTER SAW K3953M
Z102 5PK9650M-- FILTER SAW K9650M
ZZ200 PTMPJ2G177
PCB MAIN CHIP MOUNT B AS
DLP-20J1LHS
C103 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
C104 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
C107 HCQK470JBA C CHIP CERA 50V CH 47PF J 1608
C108 HCQK470JBA C CHIP CERA 50V CH 47PF J 1608
C202 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
C203 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
C206 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
C207 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
C210 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
C211 HCBK333KBA C CHIP CERA 50V X7R 0.033MF K 1608
C224 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C226 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C227 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C231 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C236 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C239 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C243 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C244 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C246 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C247 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C251 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C257 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C258 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C259 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C260 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C264 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C276 HCQK221JBA C CHIP CERA 50V CH 220PF J 1608
C277 HCQK221JBA C CHIP CERA 50V CH 220PF J 1608
C505 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C507 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C509 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C511 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
C512 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C513 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C514 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
C515 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C516 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C519 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C522 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C523 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
C532 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C539 HCBK392KBA C CHIP CERA 50V X7R 3900PF K 1608
C540 HCBK473KBA C CHIP CERA 50V X7R 0.047MF K 1608
C541 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C544 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C546 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C549 HCBH224KBA C CHIP CERA 25V X7R 0.22MF K 1608
C551 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
LOC PART CODE PART NAME DESCRIPTION REMARK
8-1. Service part list
