9. Power
9-1. PB-6024W02(The power module for DLP-20W2)
Input Requirements.
Input Voltage Range Voltage Range:AC180V to 270V Normal Voltage:AC 240V
Frequency Range Frequency Range:47 To 63Hz Normal Frequency:50 To 60Hz
Input Current 0.35 Arms at 240 Vac input
Inrush Current 240V 30A peak
Earth Leakage Current 3.5mA MAX(250AC)
Hi-Pot Test Primary to GND:3000VAC for 1 minute
Cutoff Current 10mA 3.6KVAC for 3 seconds (mass production)
Insulation Resistance
Insulation resistance shall be more then 4MΩ at 500Vdc
between primary Live Neutral line and secondary.
Input AC surge The power supply withstand 300Vrms input for 10 seconds.
Primary inlet F.G to secondary GND 25A for 3second 80mΩ MAX
Output Requirements
Board
Output Minimum Maximum Output Current
Condition
Voltage output voltage output voltage MIN NOR MAX
+24Vdc +22.6Vdc +25.2Vdc 0A 2A 2A
+15Vdc +14.0Vdc +15.6Vdc 0A 0.3A 0.6A
+9Vdc +7.75Vdc +9.45Vdc 0A 0.3A 1.3A
DEP +5Vdc +4.75Vdc +5.25Vdc 130mA 0.5A 0.5A
This is the voltage for a signal.
When attaching the product which is by the set,
+10V voltage became +8.5Vdc~+11.00Vdc.
When the product does not attach from the set,
+10V outputs are identical from 'output +24Vdc'
