-17-
Description of Each Block
4-2-6.Audio signal processing, KEY, and LED
-Flow Chart of Audio Signal
Pre AMP input
Location:CE38, CE39
MST96889LD
TDA8931T
TDA8931T
WM8521
TDA1308
Speaker L &
Headphone L
Speaker R&
Headphone R
U12
U14
12S
HDMI
PC
COMP
AV3
SC2
SC1
RF(SIF)
Sound L
Sound R
SC1-OUT
U8
U1
U13
