Main PCBs Trouble Diagnosis
6-1-3.When Control Key doses not operate
After turn on the power,
does LED turn on red light?
Check start
Y
Y
Y
N
1.Check AC connection
2.Check Power S/W ON
3.Check other PCBs
After ST-BY on Does LED
turn on green light?
N
Check the connection of
KEY PCB to MAIN PCB
=>Check the connection between
KEY PCB and MAIN PCB
Is output first pin P13 normal?
N
1.Replace the connector
2.Replace KEY PCB
Check Main PCB
