Daewoo DLT-32C2 Service Manual

-52-
10. Service part list
ZZ100 48B5655J12 TRANSMITTER REMOCON R-55J12(AAA)
ZZ110 PTACPWG233 ACCESSORY AS DLT-32C6LMBD
60 4850Q00910 BATTERY R03/NN
M212 4852176101 COVER BOTTOM ABS BK
M681 4856819300 CLAMP WIRE NYLON 66
M821 4858219401 BAG INSTRUCTION L.D.P.E T0.05X280X47
M861 485862100 MANUAL INSTRUCTION ENGLISH
P801A 48599PM005 CORD POWER AS UK LP-61L+LS-60=2.0M
ZZ120 PTBCSHG117 COVER BACK AS DLP-26C2AMSB
M211 4852175701 COVER BACK HIPS BK
M211A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M211B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M211C 4857817610 CLOTH BLACK FELT 300X20X0.7
M211D 4857818703 CLOTH BLACK FELT T1.0 L=300 W=15
M211E 4857817614 CLOTH BLACK CLOTH 150X20X0.7
M211F 4857821204 CLOTH BLACK FELT 220X12X2
M213 4852176201 COVER WIRE ABS BK
M322 4853829200 FRAME WALL KIT SECC T=2.0
M322A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
ZZ130 PTPKCPG117 PACKING AS DLP-26C2AMSB
M681 4856812400 BAND PP AUTO T1.1XW17MMXL770M
M801 4858070900 BOX CARTON DW-3
M811 485819CK00 PAD EPS
M822 4858215601 BAG P.E PE FOAM t0.5x1600x12
ZZ140 PTCACAG261 CABINET AS DLT-26C2SMDB
J10A 4859004160 CABLE LVDS 1001-31FC-N+FH10002-
M191 4851958700 SHIELD CASE AS 7256400+5944605
M201E 7003400651 SCREW MACHINE BIN 4X6 MFZN 3CR
M201F 4856815910 CLAMP WIRE EGI T0.4+TUBE+PIE 4.
M211A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M211B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M211C 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M321 4853296000 BRKT STAND SECC T=1.6
M321A 7172401252 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK
M322 4853296100 BRKT STAND BOX SECC T=1.0
M322A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M322B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M381C 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M381G 7002400852 SCREW MACHINE TRS 4X8 MFZN BK 3CR
M382 4853828900 FRAME BAR SECC T=1.2 (A-1 : AU
M382A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M382B 7002400852 SCREW MACHINE TRS 4X8 MFZN BK 3CR
M491B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M541 4855421200 SPEC PLATE P.E 149X59
M551 4855557101 DECO SENSOR PC GY
M551A 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK
M592 4855944702 DECO TERM B PVC T0.25 (SL-500T)
M721A 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK
M723 4857255905 SHIELD JACK AL 1100 T=1.0 (A-6 :
M723A 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK
M723B 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK
P803B 4850714S05 CONNECTOR 20022HS-14+20022HS-1
V901 485LD16261 LCD PANEL LTA260W3-L01
V902 4850M14410 MODULE POWER FEL-3226H
ZZ200 PTFMSJG117 MASK FRONT AS DLP-26C2AMSB
M201 4852093211 MASK FRONT HIPS GY
M201A 4857743800 CUSION PANEL PVC 400 X 10 T=1.0
M201B 4857743900 CUSION PANEL PVC 300 X 10 T=1.0
M561 48556293SD MARK BRAND SILVER DIA-CUTTING
ZZ210 PTSPPWG261 SPEAKER AS DLT-26C2SMDB
P4A 4850703S82 CONNECTOR SMH250-03+YRT205+YRT
P5A 4850702N34 CONNECTOR SMH250-02+YRT205+YRT
SP01 4858318410 SPEAKER SP-57165F01C
SP01A 4856017800 SCREW SPKR FIX SWRM+SECC 3CR
SP02 4858318410 SPEAKER SP-57165F01C
SP02A 4856017800 SCREW SPKR FIX SWRM+SECC 3CR
ZZ250 PTSNSWG117 STAND AS DLP-26C2AMSB
M191 4851957611 COVER ASSY C2 STAND SUB ASSY
LOC PART CODE PART NAME DESCRIPTION
M384 4853828811 FRAME STAND ABS GY
M521A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
ZZ290 PTMPMSG261 PCB MAIN MANUAL AS DLT-26C2SMDB
100 2193110012 SOLDER WIRE SAC3000 •’3.0MM (LFA
200 2193110024 SOLDER WIRE SAC3005 •’1.6MM (LFA
300 2291050623 FLUX SOLDER LF SV-PBF-304P(0.823)
400 2291050312 FLUX SOLVENT S-3000
C0N1 4859200440 CONN PCMCIA PC68PRA5513XZ
JP1 4859112950 JACK SCART DSSM-0378 STR
JP10 4859105340 JACK S-VHS DSW-10 (STRAIGHT)
JP11 4859117450 JACK PIN DPSS-0173S(3P ST SHI
JP2 4859112950 JACK SCART DSSM-0378 STR
JP3 4859117550 JACK PIN DPSE-0375S
JP4 4959102340 JACK PHONE SPJ-358H(3.5 STRAIGH
JP6 4959200160 CONN D-SUB SHF-015-B111-22/BR2-
JP7 97P6316100 JACK HEAD PHONE DHSE-9959
JP8 4859201170 CONN OPTICAL SENSOR OJ107A-T050-SHS
JP9 4859201460 CONN D-SUB 9P SHRA0209011
M325 4853294100 BRKT POWER SW SECC 1T
M325A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M381 4853828700 FRAME MAIN PCB SECC T=1.0
M381A 7178301052 SCREW TAPPTITE TT2 WAS 3X10 MFZN BK
M381B 7008300851 SCREW MACHINE WAS 3X8 MFZN 3CR
M381C 4956800200 CLAMP WIRE WS-A-2-19
M381D 4853748800 RETA PCB NYLON 66
P13A 4850705S34 CONNECTOR 20017HR-05+12505HS-0
P14A 4850706S49 CONNECTOR 20017HR-06+12505HS-0
P4 4859284420 CONN WAFER SMW250-03
P5 4959240520 CONN WAFER SMW250-02
P6 4859285020 CONN WAFER SMW250-09
P6A 4850709S21 CONNECTOR SMH250-09+SMH250-09+
P7 4859284920 CONN WAFER SMW250-08
P8A 4850704S86 CONNECTOR YH025-04+YH025-04+UL
P9 4859295520 CONN WAFER 4602-02MV2-60-1 PLUG
TU1 4859731230 TUNER DIGITAL TD1318AF/IHP-3(DV-IF
U10 125L8005PC IC FLASH MEMORY MX25L8005PC-15G 8M 8
U11 1M24C32BN6 IC EEPROM M24C32WRN6
U3 1M24C04BN6 IC EEPROM M24C04WRN6
U31 14C64WBN6- IC EEPROM M24C64-WBN6
X2 5XJ14R31AE CRYSTAL QUARTZ HC-49/S 14.31818MHZ
Z1 5PK9650M— FILTER SAW K9650M
Z2 5PK3953M— FILTER SAW K3953M
ZZ200 PTMPJ2G261 PCB MAIN CHIP B AS DLT-26C2SMDB
C10 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C100 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C105 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C12 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
C13 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
C132 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C136 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C14 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
C145 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C15 HCBK472KBA C CHIP CERA 50V X7R 4700PF K 160
C16 HCBK472KBA C CHIP CERA 50V X7R 4700PF K 160
C164 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C166 HCBK223KBA C CHIP CERA 50V X7R 0.022MF K 16
C168 HCBK223KBA C CHIP CERA 50V X7R 0.022MF K 16
C17 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 160
C171 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C172 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C176 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C177 HCBD105KBA C CHIP CERA 10V X7R 1MF K 1608
C182 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C183 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C184 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C185 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C186 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C187 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
LOC PART CODE PART NAME DESCRIPTION
DLT-26C2
