Daewoo DLT-32C2 Service Manual

-94-
Service part list
D45 DMMBD1204B DIODE CHIP MMBD1204
D46 DMMBD1204B DIODE CHIP MMBD1204
D48 DFM405—-C DIODE CHIP FM405
D49 DFM405—-C DIODE CHIP FM405
D50 DBAV99ML-B DIODE CHIP BAV99ML
D51 DM2FM3—-C DIODE CHIP SCHOTTKY M2FM3 M2F TYPE
D52 DM2FM3—-C DIODE CHIP SCHOTTKY M2FM3 M2F TYPE
D53 DZ02W8R2VA DIODE CHIP ZENER Z02W8.2V
D54 DZ02W8R2VA DIODE CHIP ZENER Z02W8.2V
D55 DZ02W8R2VA DIODE CHIP ZENER Z02W8.2V
D56 DZ02W8R2VA DIODE CHIP ZENER Z02W8.2V
D70 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
D71 DZ02W5R6VA DIODE CHIP ZENER Z02W5.6V
JP5 4859201360 CONN HDMI 51V019S-36WT-A1R
L1 HLC100K03B L CHIP COIL 10UH K NLCV25T-PF
L10 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L11 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L12 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L13 HFFH1M501B F CHIP FERRITE BEAD HH-1M3216-501J
L14 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L15 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L16 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L17 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L18 HFFH1M501B F CHIP FERRITE BEAD HH-1M3216-501J
L19 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L2 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L20 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L23 HFFH1M501B F CHIP FERRITE BEAD HH-1M3216-501J
L24 HFFH1M501B F CHIP FERRITE BEAD HH-1M3216-501J
L25 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L26 HLC470KECE L CHIP COIL 47UH K 1280
L27 HLC470KECE L CHIP COIL 47UH K 1280
L29 HLC100K03B L CHIP COIL 10UH K NLCV25T-PF
L3 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L30 HLC100K03B L CHIP COIL 10UH K NLCV25T-PF
L31 HLC470KECE L CHIP COIL 47UH K 1280
L32 HLC100J00A L CHIP COIL 10UH NLC322522
L33 HLC100J00A L CHIP COIL 10UH NLC322522
L34 HLC470KECE L CHIP COIL 47UH K 1280
L35 HFFH1M501B F CHIP FERRITE BEAD HH-1M3216-501J
L36 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L37 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L38 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L39 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L4 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L40 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L41 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L42 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L43 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L44 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L45 HLC479K05C L CHIP COIL 4.7UH K NLC322522T
L46 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L47 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L49 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L5 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L50 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L58 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L59 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L6 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L60 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L61 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L62 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L63 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L64 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L65 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L66 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L67 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L68 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L69 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L7 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
LOC PART CODE PART NAME DESCRIPTION
L70 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L71 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L72 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L73 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L74 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L75 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L76 HFF600C01A F CHIP FERRITE BEAD 60 OHM PBY 2012
L8 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
L9 HFF300C00A F CHIP FERRITE BEAD 30 OHM PBY 2012
P13 4859295120 CONN WAFER 12505WS-05A00
P14 4859295220 CONN WAFER 12505WS-06A00
P3 4859293820 CONN WAFER GT121-31P-TD-A 31P ST
Q1 T2SA1037KB TR CHIP 2SA1037AKT146-R
Q10 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q11 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q12 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q13 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q14 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q15 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q16 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q17 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q18 T2SA1037KB TR CHIP 2SA1037AKT146-R
Q19 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q2 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q20 T2SA1037KB TR CHIP 2SA1037AKT146-R
Q21 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q26 T2SA1037KB TR CHIP 2SA1037AKT146-R
Q27 T2SA1037KB TR CHIP 2SA1037AKT146-R
Q3 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q4 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q5 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q6 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q7 T2SC2412KB TR CHIP 2SC2412K-T146-BR
Q8 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R10 HRFT750JBA R CHIP 1/10 75 OHM J 1608
R100 HRFT184JBA R CHIP 1/10 180K OHM J 1608
R101 HRFT223JBA R CHIP 1/10 22K OHM J 1608
R104 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R107 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R108 HRFT681JBA R CHIP 1/10 680 OHM J 1608
R112 HRFT682JBA R CHIP 1/10 6.8K OHM J 1608
R114 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R115 HRFT153JBA R CHIP 1/10 15K OHM J 1608
R116 HRFT751JBA R CHIP 1/10 750 OHM J 1608
R119 HRFT222JBA R CHIP 1/10 2.2K OHM J 1608
R12 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R120 HRFT201JBA R CHIP 1/10 200 OHM J 1608
R123 HRFT221JBA R CHIP 1/10 220 OHM J 1608
R124 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R126 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R128 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R129 HRFT102JBA R CHIP 1/10 1K OHM J 1608
R130 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R133 HRFT000JBA R CHIP 1/10 0 OHM J 1608
R136 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R137 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R138 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R139 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R140 HRFT151JBA R CHIP 1/10 150 OHM J 1608
R142 HRFT102JBA R CHIP 1/10 1K OHM J 1608
R143 HRFT102JBA R CHIP 1/10 1K OHM J 1608
R144 HRFT105JBA R CHIP 1/10 1M OHM J 1608
R146 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R147 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R148 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R149 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R15 HRFT302JBA R CHIP 1/10 3K OHM J 1608
R150 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R151 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R152 HRFT103JBA R CHIP 1/10 10K OHM J 1608
LOC PART CODE PART NAME DESCRIPTION

Daewoo DLT-32C2 Specifications

General

Brand	Daewoo
Model	DLT-32C2
Category	LCD TV
Language	English
