Daewoo DLT-32C2 Service Manual

-97-
Service part list
R728 HRFT000JBA R CHIP 1/10 0 OHM J 1608
R729 HRFT000JBA R CHIP 1/10 0 OHM J 1608
R73 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R730 HRFT000JBA R CHIP 1/10 0 OHM J 1608
R731 HRFT000JBA R CHIP 1/10 0 OHM J 1608
R732 HRFT000JBA R CHIP 1/10 0 OHM J 1608
R733 HRFT000JBA R CHIP 1/10 0 OHM J 1608
R734 HRFT000JBA R CHIP 1/10 0 OHM J 1608
R74 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R75 HRFT220JBA R CHIP 1/10 22 OHM J 1608
R76 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R77 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
R78 HRFT473JBA R CHIP 1/10 47K OHM J 1608
R79 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R8 HRFT750JBA R CHIP 1/10 75 OHM J 1608
R80 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R81 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R83 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R84 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R85 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R86 HRFT750JBA R CHIP 1/10 75 OHM J 1608
R87 HRFT750JBA R CHIP 1/10 75 OHM J 1608
R89 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R9 HRFT750JBA R CHIP 1/10 75 OHM J 1608
R90 HRFT750JBA R CHIP 1/10 75 OHM J 1608
R91 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R92 HRFT103JBA R CHIP 1/10 10K OHM J 1608
R93 HRFT333JBA R CHIP 1/10 33K OHM J 1608
R94 HRFT153JBA R CHIP 1/10 15K OHM J 1608
R95 HRFT220JBA R CHIP 1/10 22 OHM J 1608
R96 HRFT470JBA R CHIP 1/10 47 OHM J 1608
R97 HRFT183JBA R CHIP 1/10 18K OHM J 1608
R99 HRFT101JBA R CHIP 1/10 100 OHM J 1608
RP1 HRTS8E101J R CHIP ARRAY 1/16 8P 100 OHM 3216
RP10 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP11 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP12 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP13 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP14 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP16 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP17 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP18 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP19 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP2 HRTS8E101J R CHIP ARRAY 1/16 8P 100 OHM 3216
RP20 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP3 HRTS8E101J R CHIP ARRAY 1/16 8P 100 OHM 3216
RP4 HRTS8E101J R CHIP ARRAY 1/16 8P 100 OHM 3216
RP7 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP8 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RP9 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
U1 1WM8521HCD IC CHIP STREO DAC WM8521HC
U12 1TDA8931TQ IC CHIP AUDIO AMP TDA8931T
U13 1TDA1308TC IC CHIP HEDPHONE DRI TDA1308T
U14 1TDA8931TQ IC CHIP AUDIO AMP TDA8931T
U16 1CD74HC53D IC CHIP LOGIC CD74HC4053M96
U18 1APW1172-D IC CHIP DC-DC CONVER APW1172
U19 1G9171863C IC CHIP REGULATOR G9117-18T63U 1.8V SOT-223
U2 1CD74HC52D IC CHIP LOGIC CD74HC4052M96
U20 1LM317BD2E IC CHIP REGULATOR LM317BD2T ADJ 1.2V 37V 1.5
U21 1G9117T63C IC CHIP REGULATOR G9117T63U ADJ SOT-223
U22 1G9173363C IC CHIP REGULATOR G9117-33T63U 3.3V SOT-223
U23 1LM317BD2E IC CHIP REGULATOR LM317BD2T ADJ 1.2V 37V 1.5
U24 1G9173363C IC CHIP REGULATOR G9117-33T63U 3.3V SOT-223
U25 1APW1172-D IC CHIP DC-DC CONVER APW1172
U26 1G9117T63C IC CHIP REGULATOR G9117T63U ADJ SOT-223
U27 1G108433TD IC CHIP REGULATOR GT1084-33T53UF 3.3V TO-263
U28 1G108418TD IC CHIP REGULATOR G1084-18T53UF 1.8V TO-263
U29 1S281632DD IC CHIP SDRAM K4S281632F-UC75
U30 1NX8314HSQ IC CHIP MEDIA PROCES PNX8314HS
U33 1320ET70NQ IC CHIP FLASH MEMORY M29W320ET70N6E
LOC PART CODE PART NAME DESCRIPTION
U34 1ST232CD-Q IC CHIP DRIVE ST232CD
U35 1C1GU04GWD IC CHIP INVERTER 74AHC1GU04GW
U36 1CD74HC53D IC CHIP LOGIC CD74HC4053M96
U37 1C1GU04GWD IC CHIP INVERTER 74AHC1GU04GW
U38 1A1334BTSD IC CHIP AUDIO DAC UDA1334BTS
U39 110046AHTD IC CHIP CHANNEL DECO TDA10046AHT
U40 1C1MAXSP2Q IC CHIP DE-SCRAMBLER CIMAX-SP2
U41 1ST890BDRC IC CHIP CURRENT SWIT ST890BDR
U42 1VC573ADBD IC CHIP LATCH 74LVC573ADB
U43 1VC573ADBD IC CHIP LATCH 74LVC573ADB
U44 1C245APW-D IC CHIP TRANSCEIVER 74LVC245APW
U5 1TDA9886T- IC CHIP IF TDA9886T
U6 128164SB5D IC CHIP DDR SDRAM V58C2128164SBI5 128M TSOP
U7 TFDS4953-C FET CHIP FDS4953 SO-8 -30V -5A REEL
U8 1T96889LDQ IC CHIP MICOM(+VIDEO MST96889LD
X5 5Z27R000TF CRYSTAL OSCILLATOR 4P 27.000MHZ 50PPM (BMS-87
ZZ310 PTUNSWG262 PCB UNION AS DLT-37C3LMBD
100 2193110012 SOLDER WIRE SAC3000 •’3.0MM (LFA3C0-W3
200 2193110024 SOLDER WIRE SAC3005 •’1.6MM (LFA3-107-
300 2291050623 FLUX SOLDER LF SV-PBF-304P(0.823)
400 2291050312 FLUX SOLVENT S-3000
IC291 1TS0P34838 IC PREAMP TSOP34838SJ
LED2 DSPR39MVW- LED SPR-39MVW (DUAL)
M232 4852333201 PANEL CTRL HIPS BK
M491 4854964311 BUTTON CH ABS GY
M491A 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
P911A 4859299720 CONN WAFER 20017WR-05A
P912B 4859299820 CONN WAFER 20017WR-06A
ZZ200 PTUNJ0G262 PCB UNION RHU AS DLT-37C3LMBD
ZZ200 PTUNJBG262 PCB UNION M-10 AS DLT-37C3LMBD
ZZ200 PTUNJRG262 PCB UNION RADIAL AS DLT-37C3LMBD
SW201 5S50101Z90 SW TACT THVV502GDA
SW202 5S50101Z90 SW TACT THVV502GDA
SW203 5S50101Z90 SW TACT THVV502GDA
SW204 5S50101Z90 SW TACT THVV502GDA
SW205 5S50101Z90 SW TACT THVV502GDA
SW206 5S50101Z90 SW TACT THVV502GDA
SW207 5S50101Z90 SW TACT THVV502GDA
ZZ200 PTUNJAG262 PCB UNION AXIAL AS DLT-37C3LMBD
A001 4859815360 PCB UNION 246X197 D1B
C997 CCZJ1H104Z C CERA 50V F 0.1MF Z AXL(1608)
R901 85801050GY WIRE COPPER 1/0.5 TIN COATING
R902 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R903 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R904 85801050GY WIRE COPPER 1/0.5 TIN COATING
R905 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R906 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R907 RD-AZ113J- R CARBON FILM 1/6 11K OHM J
LOC PART CODE PART NAME DESCRIPTION
