4. Parts List
4.1. Power parts list
NO. PART NO. DESCRIPTION QTY LOCATION
Carbon Resistor
1 M2R1130330433110 RT14-1/4W-30K-J 1 R905
2 M2R1139330433110 RT14-1/4W-39K-J 1 R902
3 M2R1110030433110 RT14-1/4W-10R-J 2 R908 R118
4 M2R1120130433110 RT14-1/4W-200R-J 2 R107,L101
5 M2R1110230433110 RT14-1/4W-1K-J 1 R110
6 M2R1110330433110 RT14-1/4W-10K-J 3 R111,R112,R102
7 M2R1122330433110 RT14-1/4W-22k-J 1 R105
8 M2R1110130433110 RT14-1/4W-100R-J 3 R108,R109,R906
9 M2R1122030433110 RT14-1/4W-22R-J 1 R904
10 M2R1147130433110 RT14-1/4W-470R-J 2 R101,R104
11 M2R112R030433110 RT14-1/4W-2R-J 2 R907,R909
12 M2R1110530233110 RT15-1/2W-1M-J 1 R900
13 M2R8833430133110 RYG1-1W-330K-J 1 R901
14 M2R8827330133110 RYG1-1W-27K-J 1 R903
15 M2R8810330133110 RYG1-1W-10K-J 1 R910
16 M2I00SS2N60B0000 SS2N60B TO220 1 Q901
AC Porcelain Capacitor
17 M2C1102G54000022 CT7-400VAC-102M 3 C903,C904,C909
18 M2C1104F84000022 CT81-50V-104-Z 5 C107,C113,C114,C117,C120
19 M2C1151M84000022 CT81-1000V-151-Z 1 C910
20 M2C1103L84000022 CT81-500V-103-Z 2 C908 C121
21 M2C1472M89000022 CT81-1000V-472-Z 1 C906
Electrolytic Capacitor
22 M2C2476K59163222 CD293-47U-400V-M-105
℃
1 C905
23 M2C2107T59061222 CD288-35V-100U-M 2 C101,C102
24 M2C2107B59051122 CD288-16V-100U-M 5 C103,C104,C105,C109,C115
25 M2C2337B59081222 CD288-16V-330U-M 1 C108
26 M2C2228C59051122 CD288-10V-2200U-M 1 C111
27 M2C2476E59051122 CD288-25V-47U-M 1 C907
28 M2C2337C59051122 CD288-10V-330U-M 1 C112
29 M2C5104F49000022 0.1uFK-275VAC 2 C901
，
C902
Diode
30 M2D1IN4007220000 1N4007-
（
DO-41A
）
5 D901
，
D902
，
D903
，
D904,D106
31 M2D1HER107220000 HER107 2 D907,D908
32 M2D1IN4148110000 1N4148-
（
DO-35
）
1 D906
33 M2D1HER104220000 HER104 3 D101,D102,D103,
34 M2D10SR360220000 SR360 1 D105
35 M2D1IN5392220000 1N5392 2 D108,D109
36 M2D1BZX12V220000 BZX-12V-1/2W-
（
DO-35
）
1 Z101
37 M2D1BZX22V220000 BZX-22V-1/2W-
（
DO-35
）
1 Z104
38 M2D1BZX5V1220000 BZX-5V1-1/2W-
（
DO-35
）
1 Z102
39 M2H20000L0710000 L071-10uH 1 L105
