4.3. Front panel parts list
NO. PART NO. DESCRIPTON QTY LOCATION
Carbon Resistor
1
M2R1110330633110 RT13-1/6W-10K-±5% 4
R1 R2 R3 R4
2
M2R1133330633110 RT13-1/6W-33K-±5% 9 R5 R6 R7 R8 R9 R10 R11 R12 R13
3
M2R1115230633110 RT13-1/6W-1K5-±5% 1 R14
Electrolytic Capacitor
4
M2C2107B89050722 SM-16V-100uF-M 2 C1,C7
Porcelain Capacitor
5
M2C1101F44000022 CC1-50V-101-K 3 C3
，
C4
，
C5
6
M2C1104F84000022 CT81-50V-104-Z 2 C2
，
C6
Diode
7
M2D11N4148110000 1N4148 2 D1
，
D2
8
M2D100374N220000 LT0374N-43-M1 1 D3
IC
9
M2I00PT6312B0000 PT6312B-QFP44 1
U2
VFD
M2G11NHV06SS9100
06SS91 1 U1
M2G00FH811806350
81*18-0635 1 U1
11
****************
JP-5MM 4 J1 J4 J5 J10
12
****************
JP-7.5MM 7 J2 J3 J6 J7 J8 J9 J15
IR
13
M2IAT13812B00000 AT138BST-12M2 1
U3
Jiggle Switch
14 M2S00KAO06060501 KAO-6*6*5(230g)
4 PLAY POWER STOP SKIP_FOR
15 M2B000HY17200S12 HY172-3500-0S0 VER1.2
1
16 M2V11121NL200103 WH121N-2-A10K-F15
2
PCB
17 M2B0HYDVD3500010 HY3500-XNVOL VER1.0
1
