Daewoo DM-K40 - 4.3. Front Panel Component List

Daewoo DM-K40 Service Manual
Page 41
NO. PART NO.
DESCRIPTION
QTY
LOCATION
84 M2I0ZR3670700000
Zoran ZR36707-PQFP64 1 U6
M2I029LV80007000 MBM29LV800BA-70 PFCN
1
U4
M2I039VF80000000 SST 39VF800A-70-4C-EK-TSOP48
1
U4
M2I039VF80000001
SST 39VF800-70-4C-EK-TSOP48
1
U4
M2I0M29W80070000 M29W800DT-TSOP48
1
U4
M2ITE28F160C0000
TE28F160C3BD70
1
U4
M2I039VF80090000
SST 39VF800-90-4C-EK-TSOP48
1
U4
M2I029W800B70000
M29W800DB-70N
1
U4
M2IM12L16161A000 M12L16161A-7T
2
U2 U3
M2IVT36171600000 VT361716T-6AA
2
U2 U3
M2ITM50S11600000 TM50S116T-7
2
U2 U3
87 M2I0CS4334K00000 CS4334K-SOIC8 1 U10
88 M2IAZ1117H330000 AZ1117H-3.3V-(SOT-223) 1 U13
89 M2IAZ11170000000 AZ1117H-ADJ(SOT-223) 1 U14
90 M2I000D595400000 D5954-HSOP28 1 U7
91 M2IAZ4558AM00000 AZ4558AM-SO8 1 U11
92 M2I00078L0500100 78L05-(TO-92) 1 U9
94
M2I0L7805CV00100 L7805CV
1
U12
95
M2I074HC14D00000 74HC14D-SO14
1
U5
96
M2I0GP1F32T00100 GP1F553TZ/554TZ
1
CN6
97
M2I0MC3407200000 MC34072-SO8
1
U18
M2IPT44720000000 PT4472 1
U18
Jack
98 M2P0000TJC35A000 TJC3-5A 1 CN1
99 M2P88FPC24005000 JP24-05M 1 CN3
100 M2P000000PH5A000 PH-5A 1 CN5
101 M2P00000PH6AB000 PH-6A-B 1 CN2
102 M2P000000PH6A000 PH-6A 1 CN4
103 M2P000000PH8A000 PH-8A 1 CN15
103 M2P660000S4KB000 S-4KB 1 CN17
105 M2P11000RCA1A000 RCA-1A-COAX 1 CN9
106 M2P11AV684120003 AV6-8.4-12-03 1 CN8
PCB
107 M2B100HY629AS013 HY629A-762-0S0 VER1.3 1 PCB
