28
◆DSB-182A-R/182P-R/183AH/183PH/182AH-R/182PH-R
DSA-183A-R/183AH-R
AIR IN
AIR OUT
Connection Cover
Remove cover to access the
AC connection from this unit to
the indoor unit.
Connection Wire
Drain Hose
O2 Hose Wire (Oxygen Models)
Connection Pipes
Service Valves
The indoor and outdoor
units are connected by
copper tubes which are
connected here.
Ground Wire
(Not supplied)
