1. SPECIFICATIONS
MODEL
DSB-071AH
ITEM
Function Cooling & Heating
Class T1
Power AC 220~240V/ 50Hz
Capacity W 2,110/2,050
Btu/h 7,200/7,000
Dehumidification l/h 1.0
Running Current A 3.1/3.1
Power Input W 740/720
Starting Current A 18
Type Rotary
Model RBB075A011
Capacitor 25µF / 370VAC
Indoor Unit Outdoor Unit
Type Cross flow fan Propeller fan
Capacitor 1.0µF 400VAC 1.8µF 400VAC
Motor Model Number YDK-8-4B YDK-35-6B/A9530BD010
Sound Level (Hi) dB(A) 39 48
Fan Speed (Hi) RPM C: 1350, H: 1200 850
Control Capillary
Charge Q'ty g 850
Type Flare
OD (Liquid/Gas) in(mm) 1/4 (6.35) 3/8 (9.52)
Dimensions (W x H x D) mm 750 x 245 x 179 654 x 549 x 256
Net Weight kg 7.0 32.5
Electrical
Data
Compressor
Fan
Motor
Refrigerant
(R-22)
Connection
◆DSB-071AH
