4
MODEL
DSB-123AH/123PH
ITEM
Function Cooling & Heating
Class T1
Power AC 220~240V/ 50Hz
Capacity W 3,430/3,870
Btu/h 11,700/13,200
Dehumidification l/h 1.5
Running Current A 5.8/6.0
Power Input W 1,300/1,320
Starting Current A 37
Type Rotary
Model RCB135U001
Capacitor 40µF/ 370VAC
Division Indoor Unit Outdoor Unit
Type Cross flow fan Propeller fan
Capacitor 1.5µF 400VAC 3.5µF 400VAC
Motor Model Number RP-13B YDK-40-4B
Sound Level (Hi) dB(A) 39 48
Fan Speed (Hi) RPM 1,350 960
Control Capillary
Charge Q'ty g 1,200
Type Flare
OD (Liquid/Gas) in(mm) 1/4 (6.35) 3/8 (9.52)
Dimensions (W x H x D) mm 815 x 285 x 195 654 x 549 x 256
Net Weight kg 9.2 34
Electrical
Data
Compressor
Fan
Motor
Refrigerant
(R-22)
Connection
◆DSB-123AH/123PH
