7
MODEL
DSB-183PH/AH
ITEM
Function Cooling & Heating
Class T1
Power AC 220~240V/ 50Hz
Capacity W 5,430/5,710
Btu/h 18,500/19,500
Dehumidification l/h 2.5
Running Current A 9.4 / 9.3
Power Input W 1,930 / 1,920
Starting Current A 41
Type Rotary
Model RCB195A001
Capacitor 40µF/ 450VAC
Division Indoor Unit Outdoor Unit
Type Cross flow fan Propeller fan
Capacitor 2µF 400VAC 3µF 400VAC
Motor Model Number IC-9430DWKF7A YDK-50-6B
Sound Level (Hi) dB(A) 43 56
Fan Speed (Hi) RPM 1,350 860
Control Capillary
Charge Q'ty g 1,400
Type Flare
OD
(Liquid/Suction)
in(mm) 1/4 (6.35) 1/2 (12.7)
Dimensions (W x H x D) mm 1080 x 298 x 200 800 x 615 x 320
Net Weight kg 14.7 51.9
Electrical
Data
Compressor
Fan
Motor
Refrigerant
(R-22)
Connection
◆DSB-183PH/AH
