ARM 7500
The ARM 7500 is used for the basic processor in Daewoo INTERNET Settop box DSN-300A.
The ARM 7500 is a multimedia processor implemented on a chip. A chip is composed of image and sound
treatment part, and other I/O treatment parts, centering the ARM 710C CPU core. The image treatment part
can display the screens of monitors, TVs or LCDs.
The I/O treatment part is used for interfaces of keyboards or joysticks.
The block diagram of the ARM 7500 is as follow:
The ARM 710C is a 32-bit RISC microprocessor module. This has a 4Kbyte cache, write buffer and ARM7
processor core with Memory Management Unit (MMU). The image block can drive high-level CDTs or low-
voltage LCD displaying devices. The image module can obtain many kinds of frequencies because it is de-
signed to drive a Voltage Controlled Oscillator (VCO) in order to supply the master frequency. The sound
block has an 8-bit analogue stereo system and a 32-bit serial sound interface suitable to drive the external
CD DAC. The clock control is flexibly designed and is divided into a CPU core clock input and the input/output
system clock including the memory system clock and image input. The power control has two modes. The
clock inputting into the CPU is suspended but display function is on in the SUSPEND mode, All clocks are
suspended in the STOP mode.
