2. DESCRIPTION OF THE EXTERNAL PORT
ITEM
TESTING POSITION
AND CONDITIONS
SPECIFICATIONS REMARKS
Main AC Both ends of the AC 120 Vac ± 10% DSN-300A
Vcc B+ VCC, GND 5V
± 5%
Image Input VGA IN 75 Standard Signal
Image Output RCA VCR 75 1Vp-p
± 5%
S-VHS 75 burst level Y: 1VP-P ± 5%
C:0.28Vp-p ±5%
VGA OUT 75 R.G.B.: 0.707 ±5%
LINEAR
DC OFFSET 0.5 V
H SYNC : 31.5kHz-40kHz
V SYNC : 50kHz-90kHz
Sound Output RCA AUDIO
(47 k or more)
1.414Vp-p
± 10%
(The standard is-3.8dBM)
Wire Keyboard or
Mouse Input
VCC, GND
KBCLK
KBDATA
MSCLK
MSDATA
5V
± 5%
Normal; high. In operation; low.
12.5 kHZ [5.0Vp-p
± 15%]
4.2 kHz[5.0Vp-p ± 15%]
11kHz[5.0Vp-p ± 15%]
2kHz[5.0Vp-p ± 15%]
Wireless Keyboard or
Wireless Mouse Input
IR When inputting using the keyboard
5Vp-p
± 15%
Printer Output PARALLEL standard output
