6. PIN
PIN NUMBER SIGNAL NAME PIN NUMBER SIGNAL NAME PIN NUMBER SIGNAL NAME
1 LA[15] 41 VDD 81 ED[3]
2 LA[16] 42 D[12] 82 ED[2]
3 LA[17] 43 D[11] 83 ED[2]
4 LA[18] 44 D[10] 84 ED[0]
5 LA[19] 45 D[9] 85 VSS
6 LA[20] 46 D[8] 86 VSYNC
7 LA[21] 47 VSS 87 VSS_CORE
8 VDD 48 D[7] 88 HSYNC
9 LA[22] 49 D[6] 89 VDD_CORE
10 VSS 50 D[5] 90 VIREF
11 LA[23] 51 D[4] 91 VDD_ANALOG
12 LA[24] 52 D[3] 92 ROUT
13 LA[25] 53 D[2] 93 BOUT
14 LA[26] 54 D[1] 94 GOUT
15 LA[27] 55 D[0] 95 VSS_ANALOG
16 LA[28] 56 VDD 96 nTEST
17 D[31] 57 PCOMP 97 nINT8
18 D[30] 58 VSS 98 nINT3
19 D[29] 59 VCLKI 99 nINT6
20 D[28] 60 VCLKO 100 INT7
21 VSS 61 VDD_SOUND 101 RA[11]
22 D[27] 62 LP 102 RA[10]
23 D[26] 63 RP 103 RA[9]
24 VDD 64 RM 104 VSS
25 D[25] 65 LM 105 RA[9]
26 D[24] 66 VSS_SOUND 106 VDD
27 D[23] 67 SIREF 107 RA[7]
28 D[22] 68 SDO_MUTE 108 RA[6]
29 D[21] 69 SCLK 109 RA[5]
30 VSS_CORE 70 SDCLK 110 RA[4]
31 D[20] 71 WS_LNR 111 RA[3]
32 VDD_CORE 72 SINK 112 RA[2]
33 D[19] 73 ECLK 113 RA[1]
34 D[18] 74 VSS 114 RA[0]
35 VSS 75 HCLK 115 VSS
36 D[17] 76 ED[7] 116 nRAS[3]
37 D[16] 77 ED[6] 117 VDD
38 D[15] 78 ED[5] 118 nRAS[2]
39 D[14] 79 VDD 119 nRAS[1]
40 D[13] 80 ED[4] 120 nRAS[0]
