10-3. PACKAGE
DESCRIPTION
NO. PART CODE PART NAME Q’s SPEC. DESC.
1 4924600100 PAD 1 EPS
2 4924500200 BAG STB 1 LDPS TO
3 4925000200 ASS’Y SET 1 DSN-300A
4 4924700100 BOX CARTION 1 SW-2, COLOR
5 4921800100 MANUAL INSTRUCTION 1 161X240
6 4921800200 INSTRUCTION DISKET 1 3.5”
7 4924500100 BA POLY 1 LDPE TO 05
8 4924700300 BOX COVER 1 SW-2
9 KEY BOARD 1
10 REMOCON 1
11 CABLE RCA AS 3P 1
12 CABLE S-VHS AS 1
13 4859000170 PLUG MODULAR AS 1
14 4855800022 LABEL SERIAL 1 FOR BOX.UL AREA
NOTES
1. KEY BOARD(9), REMOCON(10)
BUYER OPTION.
2. GENERAL ASSEMBLING FLOW (ENGINEERING)
(1) BOX CARTON+ASS’Y SET+BAG STB+PAD
(2) (1)+REMOCON+BAG POLY
(MANUAL INSTRUCTION+INSTRUCTION DISKETT)
(3) (2)+BOX COVER+KEY BOARD+CABLE
(4) (3)+LABEL SERIAL
