Daewoo DV6T834N Service Manual

28
VOLTAGE CHARTS
2. IC A/V VOLTAGE CHARTS
MODE MODE MODE
PIN No. PIN No. PIN No.
1 2.3 2.3 2.3 28 2.2 2.2 2.2 55 0.4 0.1 0.2
2 2.2 2.8 0.0 29 2.3 2.3 2.3 56 0.0 0.0 0.0
3 2.3 2.2 2.3 30 0.0 2.2 2.2 57 3.2 2.5 2.5
4 2.3 2.2 2.3 31 4.1 4.1 4.1 58 0.0 0.0 0.0
5 2.3 2.3 2.3 32 2.2 2.2 2.2 59 0.8 0.8 1.9
6 2.3 2.1 2.3 33 3.3 2.4 2.4 60 5.1 5.0 5.1
7 2.3 2.0 2.3 34 0.0 3.0 0.0 61 2.9 2.9 2.9
8 2.3 2.0 2.3 35 2.9 2.8 2.9 62 0.0 0.0 0.0
9 2.3 2.1 2.3 36 2.5 2.5 2.3 63 3.9 3.9 3.9
10 2.2 2.1 2.2 37 2.6 2.6 2.6 64 2.1 2.1 1.3
11 4.8 4.2 4.8 38 0.0 0.0 0.0 65 0.7 0.7 0.7
12 1.0 1.0 0.0 39 1.4 1.4 1.4 66 0.7 0.7 0.7
13 0.8 0.8 0.8 40 0.0 0.0 0.0 67 0.7 0.7 0.7
14 1.6 1.5 1.8 41 0.9 0.9 0.9 68 4.9 0.0 4.9
15 1.5 1.5 1.5 42 2.3 2.3 2.3 69 1.7 1.7 0.1
16 0.0 0.0 0.0 43 4.5 4.5 4.5 70 1.7 1.7 0.0
17 0.0 4.0 4.0 44 4.9 4.9 4.9 71 0.0 0.0 0.0
18 2.3 2.3 1.5 45 5.0 5.0 5.0 72 4.1 0.0 0.0
19 0.0 0.0 0.0 46 2.2 2.2 3.1 73 4.1 4.0 0.0
20 2.1 2.1 2.5 47 3.2 3.2 3.5 74 4.1 4.1 1.8
21 1.4 1.4 1.8 48 3.2 3.2 3.5 75 0.0 0.0 0.0
22 3.0 3.0 2.9 49 4.0 4.0 3.5 76 2.3 2.3 2.3
23 4.8 4.7 4.7 50 2.6 2.6 2.6 77 4.9 4.9 4.9
24 4.9 0.0 0.0 51 2.1 2.1 2.1 78 2.3 2.3 2.3
25 0.3 0.3 0.4 52 4.9 4.9 4.9 79 1.1 1.1 0.0
26 0.8 0.8 1.0 53 4.4 4.5 4.5 80 2.3 2.3 2.3
27 1.5 1.5 0.0 54 4.3 4.4 4.5
IC CHIP SW VOLTAGE CHARTS
MODE MODE
PIN No. PIN No.
1 1.6 1.6 1.1 9 2.5 2.3 2.4
2 1.1 1.1 1.1 10 7.4 7.4 7.4
3 2.5 2.3 2.4 11 7.4 7.4 7.4
4 2.5 2.3 2.4 12 2.5 2.5 2.5
5 2.5 2.3 2.4 13 2.9 2.9 2.9
6 0.0 0.0 0.0 14 2.9 2.9 2.9
7 0.0 0.0 0.0 15 1.7 1.7 1.1
8 0.0 0.0 0.0 16 12.4 12.4 12.4
REC
STOP REC PLAY
STOP REC PLAY
IC A/V (IC301) IC A/V (IC301) IC A/V (IC301)
STOP REC PLAYSTOP REC PLAY
IC CHIP SW (IC302) IC CHIP SW (IC302)
PLAY
STOP
