Operating the VCR Without a Cassette Tape
1. Remove the cassette Loading Mechanism.
2. By hand revolve the worm counterclockwise 7-8 times until pole base loading process starts automatically.
3. Then PLAY mode appears. If you want ANOTHER mode, Press the desired button.
4. If the mechanism is in the desired mode, remove the Power.
Tension Pole Position Adjustment
1. Make the mode PLAY without a cassette loaded. Refer to "Operating the VCR Without a Cassette Tape".
2. Confirm that the datum hole of the tension lever is coincident with that of the main base.
3. If the above confirmation is not satisfying, turn Band Brake Cap clockwise or counterclockwise until the two holes are
coincident with each other.
21
Fig. 7- Tension Pole Position Adjustment
