Daewoo DVN-14F6N - Page 57

54
No Pin-function Type voltage(V) Signal waveform Input/Output configuration Remarks
REC = 2.7V
31 VIDEO-IN
PB = 2.7V
REC = 1.6V
32 AGC-TC2 D.C
PB = 1.6V
REC = 0V
33 SVHS-FM-IN
PB = 3.7V
Normal
VHS 0V
MOD-OUT REC = 3.0V
34
DOC-STOP-H PB = 3.6V 3.95 DOC-STOP
REC = 0V
35 NOR-FM-IN
PB = 3.8V
REC = 1V
36 FM-EQ-OUT
PB = 3.8V
