ALIGNMENT INSTRUCTIONS
Table-B
*1 indicates the items with differnt settings each of sets.
*2 CROSS BW: Internal pattern of Device(I501:DCT814B)
Whenever you select the "CROSS BW" using volume up(
U
) or down( ) button,
the screen is changing like this;
VOL UP (
U
)
NORMAL
Z
BLACK
Z
WHITE100
Z
WHITE60
Z
CROSS
VOL DOWN ( )
MODE ADJUSTMENT ITEMS
DATA
REMARK
INITIAL RANGE
S2 Screen Adjustment - -
S5:
IF
CONTROL
AGC Auto - - Automatical adjustment
AGC Vol 3.75V - Select AGC reference voltage (3.75V)
AGC * 1 0-63 Align RF AGC threshold
VIDEO LEV 007 0-7 Must be set to 7
FM LEV 005 0-31 Must be set to 5
HFREQ 012 0-63 NOT USED
CROSS BW * 2 - - NOT USED
S6:
GEOMETRY
H CENTER (Horizontal center) * 1 0-31 Using internal cross pattern
(CROSS BW * 2)
V SIZE (Vetical Size) * 1 0-127
V CENTER (Vertical Center) * 1 0-63
V SC (Vertical S-Correction) 0 0-31 Must be set to 0
V LIN (Vertical Linearity) 20 0-31 Must be set to 20
NO SD POWER OFF NO Automatically turn off in 15min for no received signal (YES)
CROSS BW * 2 - -
HBLKR 1 0-6 Must be set to 1
HBLKL 6 0-6 Must be set to 6
S8:
WHITE
BALANCE
RD(Red Drive) * 1 0-127 Using internal 100% WHITE pattern
(CROSS BW * 2)
GD(Green Drive) 10 0-15
BD(Blue Drive) * 1 0-127
RB(Red Bias) * 1 0-255 Using internal 60% WHITE pattern
(CROSS BW * 2)
GB(Green Bias) * 1 0-255
BB(Blue Bias) * 1 0-255
CROSS BW * 2 - -
S9
D.P
Brightness * 1 0-63
sharpness 0 0-63
Color 35 0-63
Tint 22 0-63
S10 ATK(Auto Tracking) OFF - - For VCR DECK Adjustment
S11 PG Adjustment - - Automatically P.G Adjustment
S12 FACT - - Factory Initialization
Z Z Z Z
9
To Next Page
