27
TU01 5800000032 COIL OSC DE0-006
U102 4859719130 TUNER VARACTOR DT5-NF20F 2
X501 5XE3R5795C CRYSTAL QUARTZ HC-49/U 3.579545MHZ
20PPM
XS01 5XYR03276C CRYSTAL QUARTZ C-001R 32.768000KHZ
20PPM
LOC PART CODE PART NAME DESCRIPTION REMARK
XS02 5XJ16R000E CRYSTAL QUARTZ HC-49S 16.000000MHZ
30PPM
XY01 5XEX3R579B CRYSTAL QUARTZ HC-49U 3.57954M 15PPM TP
Z101 5PTSF5241P FILTER SAW TSF5241P
Z102 5PXPS45MB- FILTER CERA TPS-4.5MB TRAP (TAPPING)
LOC PART CODE PART NAME DESCRIPTION REMARK
SERVICE PARTS LIST
I
r
OPTION PARTS LIST
1. CN-081 13" / 19" DIFFERENT PARTS LIST
LOC PART NAME
DVQ-13H2FCN DVQ-19H2FCN
REMARK
PART CODE DESCRIPTION PART CODE DESCRIPTION
1 ANT ROD 4850A02510 S3BW216B (L=600 MM) X OPTION
3 TRANS ANT MATCHING 4850A00250 IMT-06 X OPTION
C402 C MYLAR CMYH3C692H 1.6KV BUP 6900PF H CMYH3C692H 1.6KV BUP 6900PF H RETRACE
C416 C MYLAR CMYE2D474J 200V PU 0.47MF J CMYE2D514J 200V PU 0.51MF J C-CAPACITOR
M191 BUTTON CTRL 4851937200 4942601+5538800 4851937100 4942501+5538700
M201 MASK FRONT 4852070800 FR HIPS BK 4852070700 FR HIPS BK
M201B SCREW CRT FIXING 4856013301 30X140 YL 4856013302 30X190 BK
M211 COVER BACK 4852153600 FR HIPS BK 4852153700 FR HIPS BK
M481 BUTTON POWER 4854855101 ABS 4854855001 ABS BK
M801 BOX CARTON 4858042700 SW-3 4858038300 DW-3 2086
M811 PAD 4858190200 EPS 14H2 4858190100 EPS 20H2
M822 BAG PE 4858215700 PE FOAM t0.5x1000X950 4858215000 PE FOAM t0.5x1200x1150
PA501 CONNECTOR 4850708N11 BIC-08T-25T+C-
20T+ULW=300
4850708N08 BIC-08T-25T+C-20T+ULW=400
PA601 CONNECTOR 4850703S53 YH025-
03+35098+ULW=500
4850703S50 YH025-03+35098+ULW=200
Q402A HEAT SINK X 4857027200 AL T1.0 HORIZONTAL TR
Q402B SCREW TAPPTITE X 7174301011 TT2 RND 3X10 MFZN HORIZONTAL TR
Q402C WASHER X 4856215201 SPCC HORIZONTAL TR
R403 R M-OXIDE FILM RS01Z309J- 1W 3 OHM J (TAPPING) RS02Z229JS 2W 2.2 OHM J SMALL HEATER
R806 R CARBON FILM RD-4Z432J- 1/4 4.3K OHM J RD-4Z682J- 1/4 6.8K OHM J POWER
R820 R M-OXIDE FILM RS02Z828JS 2W 0.82 OHM J SMALL RS02Z688JS 2W 0.68 OHM J SMALL OCP
R823 R CARBON FILM RD-AZ363J- 1/6 36K OHM J RD-AZ273J- 1/6 27K OHM J OCP
RC406 R CHIP HRFT113JCA 1/10 11K OHM J 2012 HRFT103JCA 1/10 10K OHM J 2012 X-RAY
RC502 R CHIP HRFT822JCA 1/10 8.2K OHM J 2012 HRFT682JCA 1/10 6.8K OHM J 2012 ABL
SCT01 SOCKET CRT 4859303430 PCS633A 4859303530 PCS629-03C
SP01 SPEAKER 4858314310 SP-5070A01 3W 8 OHM 48A8306000 SS-5070A01 3W 8 OHM
V01 COIL DY 58D0000082 ODY-M1489 58D0000087 CDY-S2016
V05 MAGNET CP 4850PM001- NY-225 (MINI NECK) 4850PM010- NY-88DTA
V901 CRT BARE 48A96314C3 A34KQV42X 48A96220C1 A48AGY13X
ZZ131 CRT GROUND NET 48519A4710 1401S-1015-1P 48519A5110 2001S-1015-1P
ZZ132 COIL DEGAUSSING 58G0000078 DC-1400 58G0000122 DC-2030
