PANNEL ASS'Y
1 KNOB 3613403800 DWM-160C, ABS 4.0
3613404000 ABS 4.0 161C/162C/171C/172C
2 PANEL B 3614239000 HIPS 1.0 160C/170C
3614274300 HIPS 1.0 161C/162C/171C/172C
3 DECORATOR PANEL 3611621800 ABS 1.0 161C/171C
3611621810 ABS 1.0 162C/172C
4 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 3.0
5 LEVER W.S SELECT 3613702300 PP 1.0
6 HOSE SPRAY 3613201201 PE-LD 1.0
7 TIMER SPIN 3619911200 S-160CA 1.0
8 TIMER WASH 3619911100 S-DT15NT 1.0 OPTION
3619911300 S-K16NT 1.0 OPTION
9 SWITCH DRAIN 3619043700 VP531A-2H,250VAC/15A 1.0
10 LEVER CONTROL 3613701400 POM 2.0
11 LINK VALVE 3617804200 PP BAND W6 L=784 1.0
12 BRACKET PANEL 3610606200 PP 1.0
13 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 3.0
14 SWITCH DRAIN 3619045300 VO, SZM-V15-18FA-91 1.0 PUMP MODEL
15 HARNESS DRAIN 3612790600 160CP SW DRAIN L=1100 1.0 PUMP MODEL
1 COVER SAFETY 3611419900 LDPE(DIA:286) 1.0
2 HOSE DRAIN O AS 3613224310 820MM, HANGER, NON CLAMP 1.0 NON PUMP
3 HOSE DRAIN O AS 3613218800 LD-PE/EVA L=1600 PUMP 1.0 PUMP MODEL
QTT'Y REMARKSNO. PART NAME PART CODE DESCRIPTION
QTT'Y REMARKS
ACCESSORY ASS'Y
NO. PART NAME PART CODE DESCRIPTION
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
