NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS
27 BRAKE FIX PLT AS 4505C54000 2-WAY 1.0
28 BOLT HEX 7341500811 6B-1-5X8 MFZN 3.0
29 SPRING BRAKE 4507K53010 SWC D1.0 ZN8-C 1.0
30 ASS'Y BRAKE WIRE 3619201702 SUS WIRE+PE L260 1.0
31 BOLT HEX 7341501611 6B-1-5X16 HS MFZN 3.0
32 UNIT SPIN MOTOR 3618949601 110V 60HZ W1D35EF001 1.0 T(P)
3618949201 220V 60HZ W1D35UF001 1.0 L
3618949401
220-240V 50HZ W1D35VF001
1.0 N(P), M(P)
3618950101
W1D35FF002 110/220V 50HZ
1.0 D, DUAL
3618950001
W1D35LF002 120/240V 60HZ
1.0 S, DUAL
33 CUSHION MOTOR SPIN 3611556300 PP 3.0
34 BRACKET MOTOR SPIN 3610606100 SPG 1.6T 1.0
35 SCREW TAPPING 7122502511 T2 TRS 5X25 MFZN 3.0
36 SPRING CUSHION 3615112700 SWC D=3.2 1.0
37 STOPPER 4506H14020 PE - HD 1.0
38 STOPPER LOWER 3615200800 PP 1.0
39 RUBBER DAMPING 4506H14030 NBR 1.0
40 HARNESS ASS'Y 3612757300 7510 1.0 PUMP MODEL
3612757220 800C 1.0 N,M,T,L
3612756301 7510 1.0 D,S
41 HARNESS EARTH 3612757810 UL1015 AWG18 490 1.0
42 CABLE CLAMP 3611202610 NYLON66 DA-5N 1.0
43 TAPTITE SCREW 7272400811 TT3 TRS 4*8 MFZN 1.0
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
