17
ass’y panel
NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS
1 DECO KNOB 3611630400 ABS-TR 4.0
2 KNOB 3613404700 ABS 4.0
3 DECORATOR PANEL 3611630500 ABS-TR 1.0
4 PANEL B 3614281900 HIPS 1.0
5 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 3.0
6 HOSE SPRAY 3613201201 PE-LD 1.0
7 LEVER W.S SELECT 3613702300 PP 1.0
8 BRACKET PANEL 3610607800 HIPS 1.0
9 TIMER WASH 3619911900 DXT-15SF-201, KDW5A 1.0
10 LEVER CONTROL 3613701400 POM 1.0
11 TIMER SPIN 3619911220 S-160MA 1.0
12 LINK VALVE 3617804900 PP BAND W6 L=800 1.0
13 SWITCH COVER 3619045400 GSM-V16183A4 250V 16A 1.0
14 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 5.0
15 SWITCH SELECTOR 3619045800 GSM-V16181A4 1.0 PUMP MODEL
16 HARNESS DRAIN 3612790600 160CP SW DRAIN L=1100 1.0 PUMP MODEL
ACCESSORY ASS'Y
NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS
1 COVER SAFETY 3611419900 LDPE(DIA:286) 1.0
2 HOSE DRAIN O AS 3613224310
820MM, HANGER, NON CLAMP
1.0 NON PUMP
3 HOSE DRAIN O AS 3613218800 LD-PE/EVA L=1600 PUMP 1.0 PUMP MODEL
✔ Caution
:
In this Service Manual, some parts can be changed for improving, their performance without notice in the
parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service
Information Center (http://svc.dwe.co.kr).
