ass’y main
NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS
1 ASSY CABINET PRCACA8100 DWM-200C 1.0
2 PLATE UPPER 3614525100 SGCC 0.6T 1.0
3 SCREW TAPPING 7122401011 T2S TRS 4*10 MFZN 6.0
4 COVER BACK 3611419800 SECC 0.4T 1.0
5 SCREW TAPPING 7112400811 T1 TRS 4*8 MFZN 4.0
6 BASE UNDER 3610391800 PP 1.0
7 SCREW TAPPING 7122401011 T2S TRS 4*10 MFZN 7.0
8 CUSHION SPOT 450M712010 PP 1.0
9 CUSHION MOTOR 450M712020 NR 3.0
3618961900 220~240V/50HZ,W1S35VD060 1.0 N(P)
3618949501 220~240V/50HZ,W1S42VD101 1.0 M(P)
10 MOTOR WASH
3618961600 110V/60HZ,W1S35ED060 1.0 T(P)
3618961800 220V/60HZ,W1S35UD060 1.0 L
3618961700 120V/60HZ,W1S35JD060 1.0 A
3618962000 W1S35GD060 1.0 D,S
11 SPECIAL SCREW 3616003100 M5X35 WASHER 3.0
12 PULLEY MOTOR AS
3618431700 PRESS(SGCC1.2T,D31),2.1MM
1.0 60HZ
3618431810 PRESS(SGCC1.2T,D38) 1.0 50HZ
13 WASHER PLAIN 7400108411 PW-1-8.4 MFZN 1.0
14 NUT HEX 7392800011 M8*P1.25 MFZN 1.0
15 BELT V 3616590900 A24, 200C 1.0
3618964800 AC 220~240V, 50HZ,PLASET 1.0 NP, MP
16 UNIT DRAIN PUMP AS 3618964900 AC 110V, 60HZ,PLASET 1.0 TP
3618952710 AC 110/220V, 50/60HZ 1.0 DP
17 FIXTURE PUMP 3612005700 PP 1.0 NP,MP,TP
18 SCREW TAPPING 7112402011 T1 TRS 4X20 MFZN 1.0
19 HOSE DRAIN I 3613226400 PE-LD 1.0 NP,MP,TP
3618948200 9.7/5.2 400/440 CON-4P 1.0 L,N(P)
20 UNIT CAPACITOR
3618948300 10.4/5.2 400/440 CON-4P 1.0 M(P)
3618948600 45.6/25 200/200 CON-4P 1.0 T(P)
3618950600 41.6/20.8 200/230 CON-4P 1.0 A
21 CAPACITOR WASH 4508C11010 22.8+22.8UF 1.0 D(DUAL)
4509C11020 200V 20.8UF*2 1.0 S(DUAL)
22 CAPACITOR SPIN 4509C11010 MF CAPACITOR 200V 20.8MF 1.0 D,S(DUAL)
23 HARNESS CONDENSER 3612706710 CONN A,B 1.0 D,S(DUAL)
3611332100 T VACTFK 2*0.75 2.3M GY 1.0
3611331700 A VACTFK 2*0.75 2.3M GY 1.0
3611331310 VCTF 3*0.75 2.3M GY 1.0
3611331630 H05VV-F 3*0.75 WH 1.0
3611331650 H05VV-F 3*0.75 BK 1.0
24 CORD POWER AS 3611331110 VCTF 3*0.75 2.3M GY 1.0
3611331810 H05VV-F 3*0.75 2.3M BK 1.0
3611332100 VCTFK 2*0.75 2.3M GY 1.0
3611331930 C SJT 3*18AWG 2.3M GY 1.0
3611331700 A VCTFK 2*0.75 2.3M GY 1.0
3611331700 FH05VV 3*0.75 2.3M BK 1.0
✔ Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the
parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service
Information Center (http://svc.dwe.co.kr).
