Daewoo DW-1411 - Page 18

17
ass’y panel
NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS
1 DECO KNOB 3611630400 ABS-TR 4.0
2 KNOB 3613404700 ABS 4.0
3 DECORATOR PANEL 3611630500 ABS-TR 1.0
4 PANEL B 3614281900 HIPS 1.0
5 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 3.0
6 HOSE SPRAY 3613201201 PE-LD 1.0
7 LEVER W.S SELECT 3613702300 PP 1.0
8 BRACKET PANEL 3610607800 HIPS 1.0
9 TIMER WASH 3619911900 DXT-15SF-201, KDW5A 1.0
10 LEVER CONTROL 3613701400 POM 1.0
11 TIMER SPIN 3619911220 S-160MA 1.0
12 LINK VALVE 3617804900 PP BAND W6 L=800 1.0
13 SWITCH COVER 3619045400 GSM-V16183A4 250V 16A 1.0
14 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 5.0
15 SWITCH SELECTOR 3619045800 GSM-V16181A4 1.0 PUMP MODEL
16 HARNESS DRAIN 3612790600 160CP SW DRAIN L=1100 1.0 PUMP MODEL
ACCESSORY ASS'Y
NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS
1 COVER SAFETY 3611419900 LDPE(DIA:286) 1.0
2 HOSE DRAIN O AS 3613224310 820MM, HANGER, NON CLAMP 1.0 NON PUMP
3 HOSE DRAIN O AS 3613218800 LD-PE/EVA L=1600 PUMP 1.0 PUMP MODEL
