17
PARTS DIAGRAM
NO. PART NAME PART CODE SPEC. Q'TY REMARKS
1 SPECIAL SCREW 3616002901 SUS 304, 6X19.5(NON SILOCK) 1.00
2 PULSATOR AS 3619705000 PP 1.00
3 DRAIN STRAINER 3619606400 PP 1.00
4 FILTER OVERFLOW 3611903600 PP 1.00
5 RING BASKET 3614602000 PP 1.00
6 SCREW TAPPING 7122401211 T2S TRS 4X12 MFZN 4.00
7 BASKET SPIN AS 3619102510 DWM-600FA 1.00
8 BELLOWS AS 3616401010 5510PA, 3620DE 1.00
9 FIXTURE 3612004400 PP 1.00
10 SCREW TAPPING 7122401211 T2S TRS 4X12 MFZN 3.00
11 LINK BRAKE 3617804800 PP, L2=467MM 1.00 OPTION
12 SPRING COVER 3615108820 HSW3, 600FA 2.00
13 DOOR SPIN 36117AAE00 HIPS 1.00
14 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 3.00
15 PLATE T 3614530000 PP 1.00
16 COVER I 4507K33021 PP 1.00
17 SCREW TAPPING 7122401611 T2S TRS 4X16 MFZN 5.00
18 CAP SCREW 3610909610 PP 2.00
19
BASE WATER SUPPLY
3610391600 PP 1.00
20 DOOR WASH 36117AAF00 HIPS 1.00
21 TUB 2618819600 PP 1.00
22 RROTECTOR F.B 3618303500 NBR 1.00 PUMP
23 CASE SHAFT AS 3611118500 AS, 4.0KG 1.00
24 GASKET 3612301400 NBR 1.00
25 SPECIAL NUT 3616007500 FRPP 1.00
26 PULLEY PULSATOR 3618405200 FRPP 1.00
27 NUT PULLEY 7392050611 6N-2-6 1.00
28 SPECIAL BOLT 3616008300 SM18C+SILOCK 1.00
29 CAP VALVE 3610909405 PP 1.00
30 SPRING VALVE 4505C06023 SWC WR 1.0D 1.00
31 VALVE ROD 3615406705 PP 1.00
32 BELLOWS 4509A06042 NR 1.00
33 CASE VALVE 3611119305 PP 1.00 NON PUMP
3611119400 PP 1.00 PUMP
34 INLET JOINT 3617505100 PP 1.00
TUB ASS’Y
To Next Page
