Daewoo DW-Q73D2N-LS - Page 72

71
ELECTRICAL PARTSLIST
LOC PART CODE PART NAME PART DESCRIPTION REMARK
RM08 HRFS330JBA R CHIP 1/16 33 OHM J 1608
RM09 HRTS8E330J R CHIP ARRAY 1/16 8P 33 OHM J 3216
RM10 HRFS330JBA R CHIP 1/16 33 OHM J 1608
RM11 HRFS330JBA R CHIP 1/16 33 OHM J 1608
RM12 HRFS330JBA R CHIP 1/16 33 OHM J 1608
RM13 HRFS330JBA R CHIP 1/16 33 OHM J 1608
RM14 HRFS330JBA R CHIP 1/16 33 OHM J 1608
RM15 HRFS330JBA R CHIP 1/16 33 OHM J 1608
RM16 HRFS330JBA R CHIP 1/16 33 OHM J 1608
RM17 HRFS330JBA R CHIP 1/16 33 OHM J 1608
RM18 HRFS330JBA R CHIP 1/16 33 OHM J 1608
RM20 HRTS8E750J R CHIP ARRAY 1/16 75 OHM J 8PIN 3216
RM21 HRTS8E750J R CHIP ARRAY 1/16 75 OHM J 8PIN 3216
RM22 HRTS8E750J R CHIP ARRAY 1/16 75 OHM J 8PIN 3216
RM23 HRTS8E750J R CHIP ARRAY 1/16 75 OHM J 8PIN 3216
RM24 HRTS8E750J R CHIP ARRAY 1/16 75 OHM J 8PIN 3216
RM25 HRTS8E750J R CHIP ARRAY 1/16 75 OHM J 8PIN 3216
RM26 HRTS8E750J R CHIP ARRAY 1/16 75 OHM J 8PIN 3216
RM27 HRTS8E750J R CHIP ARRAY 1/16 75 OHM J 8PIN 3216
RM28 HRFS750JBA R CHIP 1/16 75 OHM J 1608
RM29 HRFS750JBA R CHIP 1/16 75 OHM J 1608
RM30 HRFS750JBA R CHIP 1/16 75 OHM J 1608
RM31 HRFS750JBA R CHIP 1/16 75 OHM J 1608
RM32 HRFS750JBA R CHIP 1/16 75 OHM J 1608
RM33 HRFS750JBA R CHIP 1/16 75 OHM J 1608
RM35 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RM36 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RM37 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RM38 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RM39 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RM40 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RM41 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RN01 HRFS479JBA R CHIP 1/16 4.7 OHM J 1608
RN04 HRFS100JBA R CHIP 1/16W 10 OHM J 1608
RN06 HRFS479JBA R CHIP 1/16 4.7 OHM J 1608
RN07 HRFS479JBA R CHIP 1/16 4.7 OHM J 1608
RN08 HRFS222FBA R CHIP 1/16 2.2K F 1608
RN09 HRFS104JBA R CHIP 1/16 100K OHM J 1608
RN10 HRFS335JBA R CHIP 1/16 3.3M OHM J 1608
RN12 HRTS8E103J R CHIP ARRAY 1/16 8P 10K OHM J 3216
RN14 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RN21 HRFS000-BA R CHIP 1/16 0 OHM 1608
RN22 HRFS102JBA R CHIP 1/16 1K OHM J 1608
RN23 HRFS103JBA R CHIP 1/16 10K OHM J 1608
RN25 HRFS000-BA R CHIP 1/16 0 OHM 1608
RN26 HRFS000-BA R CHIP 1/16 0 OHM 1608
RN30 HRFS510JBA R CHIP 1/16 51 OHM J 1608
XF01 5XJ33R8SUF CRYSTAL QUARTZ SX/T 33.86880MHZ 50PPM
Z0042 PVMGJRVT02 PCB MPEG RADIAL AS DW-Q73D2N-LS
CA01 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CA05 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
CA06 CEXF1H109A C ELECTRO 50V RSM 1MF (4X7) TP
CA08 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CA11 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CA13 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
LOC PART CODE PART NAME PART DESCRIPTION REMARK
CA14 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CA16 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CA17 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CC07 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CC09 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CC11 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
CC16 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CC17 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CC18 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CC23 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CC24 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CC25 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CC28 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CC29 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CC30 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CC32 CEXE1C101E C ELECTRO 16V RM 100MF 5X11
CC33 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
CD10 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CD17 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CF06 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CF07 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CF08 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CF09 CEXE1C101E C ELECTRO 16V RM 100MF 5X11
CF10 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CF11 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CF71 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CM06 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CM07 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CM24 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CM46 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CM47 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CM51 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CM63 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN01 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN03 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN06 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN10 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN11 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN13 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN16 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN23 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN24 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN25 CEXE0J221S C ELECTRO 6.3V RSA 220MF 6.3X7
CN28 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN29 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CN33 CEXF1C220A C ELECTRO 16V RSM 22MF (5X7)
CN56 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CS45 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CS64 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
CS76 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CS87 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
CS99 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
LA03 5CPX101J2T COIL PEAKING 100UH(BRN-BRN)
UL01 97P65471DA PCB DVD 308X167X2
Z008 PVPWMSN786 PCB POWER MANUAL AS DW-Q73D2N-LS
