ELECTRICAL PARTSLIST
LOC PART CODE PART NAME PART DESCRIPTION
REMARK
AP01 2193100801 SOLDER WIRE SN:PB=63:37 3PI(NO FLUX)
AP02 2193011100 SOLDER WIRE 60 SNA 1.2D
AP03 2291050305 FLUX LIQUID RF-800KN
AP04 2291050306 FLUX THINNER RF-800ADD
AP05 2291140501 WAX COVER
C801 CL2EE3104M C LINE ACROSS AC 275V 0.1MF M PCX2 335M
C802 CH1TFE222M C CERA AC 4.0KV 2200PF M AD AC250V
C803 CH1TFE222M C CERA AC 4.0KV 2200PF M AD AC250V
C804 CH1TFE332M C CERA AC 4.0KV 3300PF M AD AC250V
C805 CH1TFE222M C CERA AC 4.0KV 2200PF M AD AC250V
C806 CEXF2E680V C ELECTRO 250V RSS 68MF 16X25(SG)
C811 CL2EE3104M C LINE ACROSS AC 275V 0.1MF M PCX2 335M
C821 CEXK1C102L C ELECTRO 16V RDF(KXL) 1000UF 10X20
C822 CEXK1C102L C ELECTRO 16V RDF(KXL) 1000UF 10X20
C824 CEXK1C681L C ELECTRO 16V 680UF KXL
D821 DSR303 DIODE SCHOTTKY SR303
D824 DS F2 4 G DIODE SF24G
IC801 1LTV817MDW IC PHOTO COUPLER LVT-817M-DW
IC802 1FSDM0565P IC POWER SWITCH FSDM0565RYDTU 70KHZ TO-220F-6L(F/M)
L801 5PLF2055 FILTER LINE LF-2055
P801 97P62Y04X4 CONN WAFER YW396 4P NC
P821 97P62A09A7 CONN WAFER 440052-7 PLUG 7P 2.5
PJ822 97P885X254 CONN AS 8H-8S 350MM
Q822 TFQP20N06- FET FQP20N06
R806 RS02F473JS R M-OXIDE FILM 2W 47K OHM J SMALL
T801 57M8282470 TRANS SMPS TSW-Q74D2N
VA801 D1NR10D471 VARISTOR 1NR10D471
VA802 D1NR10D471 VARISTOR 1NR10D471
Z8012 PVPWJRN786 PCB POWER RADIAL AS DW-Q73D2N-LS
C807 CMXL2G103K C MYLAR 400V MEU 0.01MF K
C808 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C809 CMXM2A183J C MYLAR 100V 0.018MF J (TP)
C810 CBXB3A101K C CERA SEMI 1KV RR 100PF K
C823 CEXF1A221V C ELECTRO 10V RSS 220MF
C826 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C827 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C828 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C830 CEXF1A221V C ELECTRO 10V RSS 220MF
C831 CEXF1A221V C ELECTRO 10V RSS 220MF
C832 CEXF1A221V C ELECTRO 10V RSS 220MF
C833 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.5) TP
C834 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
F801 5FWPS2022L FUSE WIDE TL 250V 2A CASE
IC803 1KA431AZ IC REGULATOR KA431AZ 1% TO-92
L821 56C220K686 COIL CHOKE 22UH K 27.5X0.4D
L822 56C220K686 COIL CHOKE 22UH K 27.5X0.4D
L823 56C220K686 COIL CHOKE 22UH K 27.5X0.4D
L824 56C220K686 COIL CHOKE 22UH K 27.5X0.4D
Q821 TZTC3205Y- TR KTC3205Y (2236Y)
Q822 TZTC3205Y- TR KTC3205Y (2236Y)
Q823 TZTC3205Y- TR KTC3205Y (2236Y)
Q826 TZTC3198Y- TRANSISTOR KTC3198Y-(1815Y) (AUTO)
LOC PART CODE PART NAME PART DESCRIPTION
REMARK
Q827 TZTC3203Y- TR KTC3203Y (2120Y)
Z8013 PVPWJAN786 POWER AXIAL AUTO AS DW-Q73D2N-LS
AP31 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
AP31A 2TM110620R TAPE MASKING SI-600N RED
AP31B 2TM1106200 TAPE MASKING SI-600N
D802 DZEG01C - DIODE EG01C
D803 DZ1F3E DIODE FR 1F3E
D804 DZUZ6R8BSC DIODE ZENER UZ-6.8BSC(6.70-6.97)
D806 DZN4005S DIODE IN4005S 1A 600V
D807 DZN4005S DIODE IN4005S 1A 600V
D808 DZN4005S DIODE IN4005S 1A 600V
D809 DZN4005S DIODE IN4005S 1A 600V
D823 DSF24G---- DIODE SCHOTTKY DSF24G
D824 DZ1F3E DIODE FR 1F3E
D826 DZ1F3E DIODE FR 1F3E
D827 DZN4003 - DIODE IN4003
D828 DZN4003 - DIODE IN4003
D829 DZUZ3R9BSB DIODE ZENER UZ-3.9BSB(3.92-4.14)
D830 DZUZ13BSB- DIODE ZENER UZ-13BSB(12.59-13.16V)
D831 DZN4003 - DIODE IN4003
JP801 85801060TA WIRE COPPER 0.6X52MM TAPING
JP802 85801060TA WIRE COPPER 0.6X52MM TAPING
JP803 85801060TA WIRE COPPER 0.6X52MM TAPING
JP804 85801060TA WIRE COPPER 0.6X52MM TAPING
JP805 85801060TA WIRE COPPER 0.6X52MM TAPING
JP821 85801060TA WIRE COPPER 0.6X52MM TAPING
JP822 85801060TA WIRE COPPER 0.6X52MM TAPING
JP823 85801060TA WIRE COPPER 0.6X52MM TAPING
JP824 85801060TA WIRE COPPER 0.6X52MM TAPING
JP825 85801060TA WIRE COPPER 0.6X52MM TAPING
JP826 85801060TA WIRE COPPER 0.6X52MM TAPING
JP827 85801060TA WIRE COPPER 0.6X52MM TAPING
JP828 85801060TA WIRE COPPER 0.6X52MM TAPING
JP829 85801060TA WIRE COPPER 0.6X52MM TAPING
JP831 85801060TA WIRE COPPER 0.6X52MM TAPING
R801 RC-2Z335KP R CARBON COMP 1/2 3.3M OHM K
R803 RD-4Z333J- R CARBON FILM 1/4 33K OHM J
R804 RD-4Z473J- R CARBON FILM 1/4 47K OHM J
R805 RD-AZ330J- R CARBON FILM 1/6 33 OHM J
R821 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R822 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R823 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R824 85801060TA WIRE COPPER 0.6X52MM TAPING
R825 RN-AZ132F- R METAL FILM 1/6 1.3K OHM F
R826 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R827 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R828 RD-4Z622J- R CARBON FILM 1/4 6.2K OHM J
R829 RD-4Z622J- R CARBON FILM 1/4 6.2K OHM J
R830 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R832 RN-AZ511F- R METAL FILM 1/6 510 OHM F
U800 97P65471PA PCB POWER 324X199X1.6T/4
