8. HOW TO DISASSEMBLE
1 Before service of 1. Stop the unit, remove the power cord from the receptacles.
any part. 2. Move the unit to the safe location for the suitable work.
2 Ass’y Fan Motor
- Fan Motor
- Propeller Fan
- Blower Fan
- Orifice
3 Ass’y Control Box 1. Same as the procedure 1 to 4 in the Item 2.
-
Power Switch
- Fan Switch
- Thermostat
- Capacitor
- Power Cord
4 O.L.P 1. Same as the procedure 1 to 2 in the Item 2.
2. Remove Terminal Cover from Compressor.
- Remove hex-nut (1 point).
Please refer to the chapter 11 (Exploded diagram and parts list).
1. Remove Front Grill.
- Remove Filter Pre.
- Remove screws(2 points) in Front Grill.
2. Remove Cabinet from the unit.
- Remove screws(7 point) from the unit’s sides.
3. Remove screw(1 point) from Earth Wire and EVA end plate
4. Remove clamp cord.
- Remove screw(1 point) from the Pan Base.
5. Remove Ass’y Control Box.
- Remove wires in the each components.
6. Remove Plate Scroll and Scroll Upper.
- Remove Sealing Scroll from two scrolls.
7. Remove screws(6 point) from Ass’y Fan Motor’s sides.
- Ass’y Fan Motor is assembly of Fan Motor, Propeller and
Blower Fan and Orifice.
8. Lift Ass’y Fan Motor from the unit.
9. Remove Clip Fan(2 point) from the shaft of Fan Motor.
10. Remove Propeller Fan from the shaft of Fan Motor.
11. Remove Blower Fan from the shaft of Fan Motor.
To Next Page
