16
■ Duct + Duct pipe as
No. PARTS NAME PARTS CODE DESCRIPTION Q’TY REMARK
E01 UNIT FAN MOTOR 36189L3Z41
ISM-77806DWWA, 24V CW 8P 14W
1
E02 COVER DUCT 3611426600 PBT+GF30% 1
E03 DUCT B UPPER 361A200200 AL, 2.5T, DWD-100DR 1
E04 CLAMP CORD 3611203330 DABE-1, A=9, B=5.3, L=105 4
E05 FAN AS 3611885700 Ø133x45L IMPELLER 1
E06 SCREW TAPPING 7122400811 T2S TRS 4x8 MFZN 3
E07 WASHER PLAN 7400432011 PW4.3x20xIT 1
E08 FUSE TEMPERATURE 361A800120 120°C DF-128S 15A 250V VDE 1
E09
FRAME HEATER FRANGE
3612204100 SBHG 1.0T 1
E10 DUCT B THERMOSTAT 361A200100 AL 1
E11
PACKING THERMOSTAT
3614009900 SILICON 1
E12 SWITCH THERMOSTAT 3619046500 ON 120°C, OFF 150°C 230V 1
E13 HEATER DRY 3612800900 220V 210W, 23.050HM, 6.1W/SQ 1
3612801400 230V 2.1KW, 25.190HM, 6.1W/SQ 1
3612801600 240V 2.1KW, 27.430HM, 6.1W/SQ 1
3612801300 110V, 1.2KW, 10.080HM, 3.5W/SQ 1
3612801800 120V 1.2KW, 120MH 3.5W/SQ 1
E14 THERMISTOR DRY 361AAAAC00 R40=26.065k, R90=4.4278k 1
E15 PACKING RUBBER 3614009800 SILICON, DWD-100DR 1
E16 CUSHION DRY 3611562800 NBR, DWD-100DR 2
E17 GASKET SEAL A 3612320820 DWD-110RP, O TYPE ø5, L=1385 1
E18 GASKET SEAL B 3612320830 EPDM FOAM L=415, ø5 1
E19 GASKET INLET 3612320900 DWD-100DR 1
E20 DUCT GUIDE 361A201000 ALDC, DWD-110RP 1
E21 DUCT PIPE AS 361A200700 11kg 1
E22 CLAMP AS(DUCT) 3611203700 DUCT 2
E23 BELLOWS DUCT 3616403000 EPDM 1
To Next Page
