22
■ Base u as
No. PARTS NAME PARTS CODE DESCRIPTION Q’TY REMARK
H01 BALANCER WEIGHT AS 3616106200 6.5kg 1
H02 PIPE JOINT 3614404900 PP 1
H03 CLAMP(HODE PIPE) 3611204300 ø14, MFZN 1
H04 HOSE JOINT 3613266500 EPDM 1
H05 GASKET 3612320700 EPDM, DRY 1
3612321200 EPDM, WASH 1
H06 CLAMP GASKET AS 3611203600 GASKET 1
H07 SPRING SUSPENSION F 3615113500 YELLOW 2
H08 TUB FRONT 3618820401 PP+GF, FH7300GM 1
H09 FIXTURE HEATER 3612006700 SUS 1
H10 DAMPER PIN 361A700200 AKS, D=14.5 3
H11 DAMPER FRICTION 361A700100 70N AKS ST=170-260 3
H12 DRUM AS 3617003300 11kg 1
H13 UFT AS 361A400300 11kg 1
H13 LIFT 361A400600 PP 1
H14 SPIDER AS 361A300200 11kg 1
H15 DRAIN HOUSING I 36196TAM00 PP, PUMP 1
H16 HOSE DRAIN 3613269000 EPDM, PUMP 1
H17 AIR TRAP AS 3610AAR101 110RP, HOSE+TRAP 1
H18
SPRING SUSPENSION R
3615113600 BLACK 2
H19 GASKET TUBE 3612321100 EPDM FORM 1
H20 WATER SEAL 361A600100 NBR 1
H21 BEARING INNER 3616303100 6206Z, FAG 1
H22 BEARING HOUSING 3616303000 ALDC 1
H23 BEARING OUTER 3616303200 6205Z, FAG 1
H24 HOSE AIR 3613266300 EPDM 1
H25 UNIT BUBBLE PUMP 36189L4110 220-240V, 50/60Hz 1
36189L4G00 100-130V, 50/60Hz 1
H26 BASE 3610392000 SECEN 1
H27 UNIT STATER BLDC 36189L4800 ø256x28H, 36 SLOT, 2SENSOR 1
H28 UNIT ROTOR BLDC 36189L4900
MAGNET24, SERRATION:3114D02000
1
H29 HEATER WASH 3612800800 230V 2KW, 24.20HM, 8.6W/SQ 1
3612801200 2220V 2KW, 26.450HM, 8.6W/SQ 1
3612801500 240V 2KW, 28.80HM, 8.6W/SQ 1
3612801100 110V 1KW, 4.3W/SQ SUS 1
3612801900 120V, 1KW, 14.4MH, 4.3W/SQ SUS 1
H30 NOZZLE SHOWER 3618104000 PP 1
H31 CLAMP HOSE 3611203410 SK5, D+33 1
To Next Page
