26
2-3. DOOR S/W
1) The working principle of Door S/W
1 Door Locking
Bimetal on ( 3 sec) --> solenoid (supply 20msec pulse 2 times)
2 Door Unlocking
Bimetal off --> solenoid (supply 20msec pulse, until unlock)
3 After door locking, all parts can work normally.
4 After pressing power button, if the temperature of wash thermistor is over 50°C or the water level is
over the safety level, the door will be locked.
6 The door will be unlocked immediately after all processes are finished.
7 The door can be opened during processing if there is no problem to unlock.
